Xtreamer Pro User Manual

English
10
Specification
Specifications subject to change without prior notice
Product Name Xtreamer Pro
Processor RTD1283DD(+) 400MHz Processor
Operating System 256MB DDR2 SDRAM, 256MB Flash RAM
File System Linux
Supported File
& Formats
Video
Formats
ASF / AVI / DIVX / FLV / IFO / ISO / M2P / M2TS / M2V / M4V / MKV /
MOV / MP4 / MPEG / MPG / MTS / RMVB / TP / TRP / TS / VOB /
WMV
Video
Codecs
XVID SD/HD / MPEG1, VCD 1.0/2.0, SVCD / HD MPEG2 (up to
MP@HL1080i), ISO/IFO/VOB/TS / HD MPEG4
SP/ASP(720p/1080i/1080p), Xvid / H.264 BP@L3, HP@4.1 /
WMV9/VC-1 AP@L3 / RealVideo 8/9/10, up to 720@30P /
DviX3/4/5/6/7 (Licensee Only)
Audio
Formats
AAC / AC3 / DTS / FLAC / FLC / M3U / M3U8 / M4A / MP1 / MP2 /
MP3 / MPA / OGG / PCM / RA / RM / WAV / WMA
Audio
Codecs
Dolby® Digital Plus, TrueHD / DTS HD Master Audio, High
Resolution, LBR / 7.1 down-mix / WMAWMA Pro, Dolby® Digital
AC3 and DTS® (Licensee Only) / MPEG I Layer 1, 2, 3 (2-CH) and
MPEG II Layer 1, 2 (Multi-Channel) / LPCM,ADPCM, FLAC, AAC,
WAV, and OGG Vorbis / RA1/RA-cook/RA-lossless
HD JPEG/BMP/GIF/MGIF(Not Act)/PNG/TIFF/TIF /
HD JPEG with unlimited resolution(40M-pixel tested) / Full-pixel
(Progressive JPEG Not support)
Subtitle SRT, SMI, SUB, SSA, SUB+IDX, ASS, PGS
Video Output Composite and HDMI1.3
Audio Output
Analog Stereo RCA
Digital Optical
TV System NTSC, PAL or HDMI Auto
Hi-Def Decoding HD HDMI(480P, 576P, 720P 50HZ/60HZ , 1080i 50HZ/60HZ, 1080P 50HZ/60HZ)
Networking
Wired Ethernet (10/100) LAN via RJ-45 Port
Wireless USB host port (Optional)
Network Security Wireless : WEP, WPA
Network Protocol
Wireless : IEEE802.11N, 3dBi USB antenna(Optional)
Wired : 10/100Mbps Fast Ethernet (RJ45)
TCP/IP (DHCP client mode, Static IP mode)
Hard-Disk Type 3.5” Internal SATA I/II
USB Interface
USB2.0 Host x 2
USB2.0 Slave x 1
eSATA x 1
Power DC 5V/4.2A , 12V, 3A
Dimension 82mm(W) X 120mm(H) X 180mm(D)
