SHALLOW WELL JET ASSEMBLIES FOR CONVERTIBLE PUMPS
SHALLOW WELL JET ASSEMBLIES FOR CONVERTIBLE PUMPS
RECOMMENDED DEEP WELL JET ASSEMBLIES AND CONTROL VALVE SETTINGS
AV21 is built-in
NOTE: Offset adapters are available. See “Fittings” section of your Goulds Water Technology Jet and Sub Catalog or consult
your local distributor for information.
CHART 1 (continued)
PUMP MODEL
SHALLOW WELL ASSEMBLY INCLUDES
ORDER NO.
NOZZLE VENTURI
J5 FH5 (std.) AN017 AD3731
J5 FH5H (high pres.) AN019 AD3528
JRD5 FH5JRD AN018 AD3731
J7, JRD7 FH7 AN018 AD3536
J10, JRD10 FH10 AN018 AD3538
J15 FH15 AN022 AD3542
HSJ07N FHSJ07 AN012 AD3432
HSJ10N FHSJ10 AN012 AD3437
HSJ15N FHSJ15 AN012 AD3439
HSJ20N FHSJ20 AN012 AD3448
CHART 2
RECOMMENDED DEEP WELL JET ASSEMBLIES AND CONTROL VALVE SETTINGS
PUMP
TWIN PIPE SYSTEMS (see g. 2) PACKER SYSTEMS (see g. 3)
RECOMMENDED
MODEL
JET MIN. WELL CONTROL VALVE DEPTH JET WELL CONTROL VALVE DEPTH PACKER CONTROL VALVE
ASSEMBLY DIAMETER SETTING (PSI) TO JET ASSEMBLY DIAMETER SETTING (PSI) TO JET ADAPTER
(see g. 4)
FT3-09 3" 30 30-50 FP2-13 2" 30 30-50
FT4B-13 4" 30 30-50 AV15
JRD5 FT4B-31 4" 30 30-70 FP2-31 2" 30 30-60 AWJ2 or
FT4B-08 4" 30 60-90 FP2-08 2" 30 60-80 AV22KIT
FT5B-14 4½" 30 70-90
FT4B-14 4" 27 30-60 FP2-40 2" 30 30-60
FT4B-34 4" 29 60-90 FP2-47 2" 32 60-90 AWJ2
AV22KIT
JRD7 FT4B-18 4" 30 90-110
AV22 and JDW
FT5B-47 4½" 27 30-70 NA
FT5B-48 4½" 30 70-110
FT4B-44 4" 31 30-60 FP2-48 2" 35 30-60
FT4B-43 4" 33 60-80 FP2-43 2" 36 60-100 AWJ2
AV22KIT
JRD10 FT4B-18 4" 35 80-110
AV22 and JDW
FT5B-49 4½" 28 30-80
NA
FT5B-11 4½" 32 80-120
FT4B-46 4"
23
30-60 FP2-38
2"
30-60
AWD2
VJ05
FT4B-08 4" 60-90 FP2-08 23 60-90
30-60 FP3-42
3"
30-60
AWD3
60-100 FP3-09 60-100
FT4B-47 4"
34
30-60 FP2-50 30-60
FT4B-46 4" 60-90 FP2-47 2" 60-100 AWD2
VJ07 FT4B-06 4" 40 90-110 FP2-09 34 100-120
FP3-40
3"
30-60
AWD3
FP3-43 60-130
FT4B-14 4" 34 30-90 FP2-48 30-60
FT4B-09 4" 36 90-120 FP2-43 2" 36 60-100 AWD2
VJ10 FP2-08 100-120
FP3-40
3"
34 30-90
AWD3
FP3-49 36 90-140
