CNTL-2 Unit (Lot.8~)
VX-8R/E and VX-8DR/E Technical Supplement
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
R 9226 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 8- B b4
R 9227 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 8- B a4
R 9228 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 8- B b4
R 9229 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 8- B b4
R 9230 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 8- B b4
R 9231 CARBON FILM RES. 10k 1/6W 5% RD16PJ103 10K J01225103 8- B b4
R 9231 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 16- B b4
R 9232 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 W/ CE LABEL 8-
R 9233 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 16- B b4
R 9234 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 16- B a4
R 9235 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 16- B a4
R 9236 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 24- B a2
R 9237 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 24- B a4
S 9001 ROTARY ENCODER TP70N1062E20 RY-8540 Q9000896 8- B a1
S 9002 TACT SWITCH SKRWAEE030 N5090156 8- A A 1
S 9003 TACT SWITCH EVQPQHB55 N5090103 8- A A2
S 9004 TACT SWITCH SKRWAEE030 N5090156 8- A A 2
S 9005 TACT SWITCH EVQPQHB55 N5090103 8- A A3
S 9006 TACT SWITCH EVQPQHB55 N5090103 8- A A3
S 9007 TACT SWITCH EVQPQHB55 N5090103 8- A A4
S 9008 TACT SWITCH EVQPQHB55 N5090103 8- A A4
S 9009 TACT SWITCH EVQPQHB55 N5090103 8- A A4
S 9010 TACT SWITCH EVQPQHB55 N5090103 8- A A4
S 9011 TACT SWITCH EVQPQHB55 N5090103 8- A B4
S 9012 TACT SWITCH EVQPQHB55 N5090103 8- A B4
S 9013 TACT SWITCH EVQPQHB55 N5090103 8- A A4
S 9014 TACT SWITCH EVQPQHB55 N5090103 8- A A4
S 9015 TACT SWITCH EVQPQHB55 N5090103 8- A B4
S 9016 TACT SWITCH EVQPQHB55 N5090103 8- A B4
S 9017 TACT SWITCH EVQPQHB55 N5090103 8- A B4
S 9018 TACT SWITCH EVQPQHB55 N5090103 8- A B4
S 9019 TACT SWITCH SKRWAEE030 N5090156 8- A C2
S 9020 TACT SWITCH EVQPQHB55 N5090103 8- A C4
S 9021 TACT SWITCH EVQPQHB55 N5090103 8- A C4
S 9022 TACT SWITCH EVQPQHB55 N5090103 8- A C4
TH9001 THERMISTOR NCP15WL473J03RC G9090175 8- B c2
X 9001 XTAL AT-38 9.8304MHz 9.8304MHZ H0103383 8-
X 9002 XTAL NX3215SA 32.768kHz 32.768KHZ 7P H0103399 24- B c1
X 9003 XTAL AT-38 4.9152MHz 4.9152MHZ H0103381 8-
X 9004 XTAL AT-38 6.144MHz 6.1440MHZ H0103384 8-
LCD HOLDER RA1016500 8-
CONTACT RA101360A 8-
SHEET(LCD) RA1013800 8-
DOUBLE FACE(LCD) RA101740A 8-
SHIELD SHEET RA108050B 15-
ELEC. COND TAPE(10X20) RA1107400 8-
