Yaesu VX-8R/E - CNTL Unit Parts List (Lot.1~7) VX-8 R Type Only

77
CNTL Unit (Lot.1~7)
VX-8R/E Technical Supplement
PCB with Components
The CNTL Unit PCB is no longer available for lots 01 to 07.
The New CNTL-2 Unit is not compatible for lots 01 to 07.
If the new CNTL-2 Unit is installed, RF-2 Unit and CONNECTOR-2 Unit must also be installed.
Printed Circuit Board FR018230E 1-4
FR018230F 5-7
BT2001 LI-ION BATTERY ML614R-TT31 Q9000895 1- B c1
C 2002 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1
C 2003 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B a4
C 2004 CHIP TA.CAP. 100uF 4V TEESVA0G107M8R K78060051 1- B a4
C 2005 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 2006 CHIP TA.CAP. 220uF 4V TEESVC0G227M12R K78060053 1- B a1
C 2007 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B a2
C 2008 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2
C 2009 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B a2
C 2010 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2
C 2011 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A A2
C 2012 CHIP TA.CAP. 47uF 4V TEESVP0G476M8R K78060050 1- B b1
C 2013 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b1
C 2014 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 2015 CHIP TA.CAP. 47uF 4V TEESVP0G476M8R K78060050 1- B b4
C 2016 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 2017 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b4
C 2018 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B c4
C 2019 CHIP TA.CAP. 22uF 20V TEMSVC1D226M12R K78130030 1- B c4
C 2021 CHIP TA.CAP. 47uF 4V TEESVP0G476M8R K78060050 1- B a1
C 2022 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2
C 2023 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B a2
C 2025 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b1
C 2026 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B a1
C 2027 CHIP CAP. 4.7uF 4V BJ AMK105BJ475MV-F K22068801 1- B a4
C 2028 CHIP CAP. 4.7uF 4V BJ AMK105BJ475MV-F K22068801 1- B a4
C 2029 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b4
C 2030 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 2031 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 2032 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B a4
C 2033 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B a2
C 2036 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B c2
C 2037 CHIP CAP. 6pF 50V CH UMK105CH060DV-F K22178254 1- B b2
C 2038 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B b2
C 2039 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2
C 2040 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B b3
C 2041 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B a1
C 2042 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- A C1
C 2044 CHIP CAP. 3pF 50V CJ UMK105CJ030CV-F K22178251 1- B b2
C 2045 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B b2
C 2046 CHIP CAP. 0.47uF 6.3V B GRM155B30J474KE18D K22088802 1- A B1
C 2047 CHIP CAP. 0.47uF 6.3V B GRM155B30J474KE18D K22088802 1- A B1
C 2048 CHIP CAP. 0.47uF 6.3V B GRM155B30J474KE18D K22088802 1- A B1
C 2049 CHIP TA.CAP. 47uF 4V TEESVP0G476M8R K78060050 1- B a2
C 2052 CHIP CAP. 0.47uF 6.3V B GRM155B30J474KE18D K22088802 1- A B1
C 2053 CHIP CAP. 0.47uF 6.3V B GRM155B30J474KE18D K22088802 1- A B1
C 2054 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- A B1
C 2055 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- A A1
C 2056 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- A A1
C 2057 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- A A1
Parts List
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
