Yaesu VX-8R/E - Unit Parts List (Lot.8~) VX-8 R and VX-8 DR;E Type

53
RF-2 Unit (Lot.8~)
VX-8R/E and VX-8DR Technical Supplement
PCB with Components CP9443002 TYP:A2U(USA)
(with RF UNIT, CNTL UNIT, CONNECTOR UNIT, MAIN VCO UNIT, SUB-VCO) CP9443003 TYP:A1(EXP)
CP9443004 TYP:A2(EXP)
CP9443005 TYP:A3(EXP)
CP9443006 TYP:B1(EU)
CP9443007 TYP:B2(EU)
CP9443008 TYP:B3(EXP)
CP9443009 TYP:C1(EU)
CP9443010 TYP:C2(EU)
CP9443011 TYP:C3(EXP)
CP9443012 TYP:D1(EU)
CP9443013 TYP:D2(EU)
CP9443014 TYP:H1(AUS)
CP9443015 TYP:H2(AUS)
Printed Circuit Board FR019730A 8-
FR019730B 16-
FR019730C 24-
C 8001 CHIP CAP. 2pF 50V CK UMK105CK020CV-F K22178250 8- B c1
C 8002 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 8- A A3
C 8003 CHIP CAP. 68pF 50V CH UMK105CH680JV-F K22178278 8- A A1
C 8004 CHIP CAP. 68pF 50V CH UMK105CH680JV-F K22178278 8- A A1
C 8005 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 8- B b1
C 8006 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 8- B b1
C 8009 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 8- B c3
C 8010 CHIP CAP. 2pF 50V CK GRM1554C1H2R0CZ01D K22178204 8- B c1
C 8011 CHIP CAP. 5pF 50V CH UMK105CH050CV-F K22178253 8- B b1
C 8014 CHIP CAP. 7pF 50V CH UMK105CH070DV-F K22178255 8- A B1
C 8015 CHIP CAP. 100pF 50V CH UMK105CH101JV-F K22178282 8- A B1
C 8016 CHIP CAP. 33pF 50V CH UMK105CH330JV-F K22178270 8- A A1
C 8018 CHIP CAP. 100pF 50V CH UMK105CH101JV-F K22178282 8- A B2
C 8019 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A B2
C 8020 CHIP CAP. 33pF 50V CH UMK105CH330JV-F K22178270 8- B b1
C 8021 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 8- B b1
C 8022 CHIP CAP. 68pF 50V CH GRM1552C1H680JZ01D K22178232 W/ CE LABEL 8- B b1
C 8022 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 W/O CE LABEL 8- B b1
C 8023 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 8- B b1
C 8029 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 8- A B1
C 8030 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 8- A A1
C 8031 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A A3
C 8032 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 8- A A3
C 8033 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 8- B c3
C 8034 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 8- B c3
C 8035 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B a4
C 8036 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B a4
C 8037 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A B2
C 8038 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A B2
C 8039 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A C2
C 8040 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A A3
C 8041 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A C1
C 8042 CHIP CAP. 3pF 50V CJ UMK105CJ030CV-F K22178251 8- A C1
C 8043 CHIP CAP. 8pF 50V CH GRM1552C1H8R0DZ01D K22178210 8- A C1
C 8044 CHIP CAP. 4pF 50V CH UMK105CH040CV-F K22178252 8- A B2
C 8045 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A B2
C 8046 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A A2
C 8047 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 8- A A2
C 8048 CHIP CAP. 0.5pF 50V CK UMK105CK0R5CV-F K22178247 8- A B2
C 8050 CHIP CAP. 56pF 50V CH UMK105CH560JV-F K22178276 8- A A2
C 8051 CHIP CAP. 4pF 50V CH UMK105CH040CV-F K22178252 8- A B2
C 8052 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A B2
C 8053 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A B2
Parts List
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
