Yaesu VX-8R/E - CNTL-2 Unit Parts List (Lot.8~) VX-8 R;E and VX-8 DR;E Type

93
CNTL-2 Unit(Lot.8~)
VX-8R/E and VX-8DR/E Technical Supplement
PCB with Components CB4804002 TYP:A2U(USA)
CB4804003 TYP:A1(EXP)
CB4804004 TYP:A2(EXP)
CB4804005 TYP:A3(EXP)
CB4804006 TYP:B1(EU)
CB4804007 TYP:B2(EU)
CB4804008 TYP:B3(EXP)
CB4804009 TYP:C1(EU)
CB4804010 TYP:C2(EU)
CB4804011 TYP:C3(EXP)
CB4804012 TYP:D1(EU)
CB4804013 TYP:D2(EU)
CB4804014 TYP:H1(AUS)
CB4804015 TYP:H2(AUS)
Printed Circuit Board FR019740A 8-
FR019740B 16-
FR019740C 24-
BT9001 LI-ION BATTERY ML614R-TT31 Q9000895 8- B c1
C 9002 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B b1
C 9003 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 8- B a4
C 9005 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B b4
C 9006 CHIP TA.CAP. 220uF 4 V TEESVC0G227M12R K78060053 8- B a1
C 9007 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 8- B a2
C 9008 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B a2
C 9009 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 8- B a2
C 9010 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B a2
C 9011 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- A A2
C 9012 CHIP TA.CAP. 47uF 4V TEESVP0G476M8R K78060050 8- B b1
C 9013 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 8- B b1
C 9014 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B a4
C 9015 CHIP TA.CAP. 47uF 4V TEESVP0G476M8R K78060050 8- B b4
C 9016 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B b4
C 9017 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 8- B b4
C 9018 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 8- B c4
C 9019 CHIP TA.CAP. 22uF 20V TEMSVC1D226M12R K78130030 8- B c4
C 9021 CHIP TA.CAP. 47uF 4V TEESVP0G476M8R K78060050 8- B a1
C 9022 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B a2
C 9023 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 8- B a2
C 9025 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 8- B b1
C 9026 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 8- B a1
C 9027 CHIP CAP. 4.7uF 4V BJ AMK105BJ475MV-F K22068801 8- B a4
C 9028 CHIP CAP. 4.7uF 4V BJ AMK105BJ475MV-F K22068801 8- B a4
C 9029 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 8- B b4
C 9030 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B c4
C 9031 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B b4
C 9032 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 8- B a4
C 9032 CHIP CAP. 4.7uF 4V BJ AMK105BJ475MV-F K22068801 24- B a4
C 9033 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 8- B a2
C 9036 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 8- B c2
C 9037 CHIP CAP. 6pF 50V CH UMK105CH060DV-F K22178254 8- B b2
C 9038 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 8- B b2
C 9039 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 8- B a2
C 9040 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 8- B b3
C 9041 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 8- B a1
C 9042 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 8- A C1
C 9044 CHIP CAP. 3pF 50V CJ UMK105CJ030CV-F K22178251 8- B b2
C 9045 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 8- B b2
C 9046 CHIP CAP. 0.47uF 6.3V B GRM155B30J474KE18D K22088802 8- A B1
C 9047 CHIP CAP. 0.47uF 6.3V B GRM155B30J474KE18D K22088802 8- A B1
C 9048 CHIP CAP. 0.47uF 6.3V B GRM155B30J474KE18D K22088802 8- A B1
Parts List
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
