115VX-8R/E and VX-8DR/E Technical Supplement

PCB with Components CB4394001

Printed Circuit Board FR015870B 1-

C 5001 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-

C 5004 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1-

C 5005 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1-

C 5007 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1-

C 5008 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BZ01D K22178291 1-

C 5009 CHIP CAP. 22pF 50V CH GRM1552C1H220GZ01D K22179707 1-

C 5010 CHIP CAP. 4pF 50V CH UMK105CH040CV-F K22178252 1-

C 5011 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-

C 5012 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1-

C 5013 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-

C 5018 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1-

C 5019 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1-

C 5020 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1-

C 5021 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-

C 5022 CHIP CAP. 51pF 50V CH GRM1552C1H510GZ01D K22179710 1-

C 5023 CHIP CAP. 47pF 50V CH GRM1552C1H470GZ01D K22179709 1-

C 5024 CHIP CAP. 4pF 50V CH UMK105CH040CV-F K22178252 1-

C 5025 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-

C 5026 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1-

C 5028 CHIP CAP. 33pF 50V CH UMK105CH330JV-F K22178270 1-

C 5031 CHIP CAP. 68pF 50V CH UMK105CH680JV-F K22178278 1-

C 5032 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-

C 5033 CHIP CAP. 5pF 50V CH UMK105CH050CV-F K22178253 1-

C 5034 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1-

C 5035 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1-

C 5036 CHIP CAP. 47pF 50V CH UMK105CH470JV-F K22178274 1-

C 5037 CHIP CAP. 10pF 50V CH UMK105CH100DV-F K22178258 1-

C 5038 CHIP CAP. 15pF 50V CH UMK105CH150JV-F K22178262 1-

C 5039 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-

C 5040 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-

C 5041 CHIP CAP. 10pF 50V CH UMK105CH100DV-F K22178258 1-

C 5042 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-

C 5043 CHIP CAP. 10pF 50V CH UMK105CH100DV-F K22178258 1-

C 5044 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-

C 5045 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-

C 5047 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1-

C 5048 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1-

D 5001 DIODE HVC355B TRF-E G2070588 1-

D 5003 DIODE HSC277TRF-E G2070584 1-

D 5004 DIODE 1SV325(TPH3.F) G2070848 1-

D 5006 DIODE HSC277TRF-E G2070584 1-

D 5007 DIODE 1SV325(TPH3.F) G2070848 1-

D 5008 DIODE 1SV325(TPH3.F) G2070848 1-

D 5010 DIODE 1SS400 TE61 G2070634 1-

D 5011 DIODE 1SS400 TE61 G2070634 1-

D 5012 DIODE 1SS400 TE61 G2070634 1-

D 5013 DIODE 1SV325(TPH3.F) G2070848 1-

D 5014 DIODE HSC277TRF-E G2070584 1-

D 5015 DIODE 1SV325(TPH3.F) G2070848 1-

J 5001 CONNECTOR AXK5F10335YP P1091136 1-

J 5002 CONNECTOR AXK5F10335YP P1091136 1-

L 5001 M.RFC 1uH LK1608 1R0K-T L1690687 1-

L 5002 M.RFC 0.0082uH 2% C1608CB-8N2G-RF L1691226 1-

L 5003 M.RFC 0.0082uH 2% C1608CB-8N2G-RF L1691226 1-

L 5004 M.RFC 1uH LK1608 1R0K-T L1690687 1-

L 5005 M.RFC 2.2uH LK1608 2R2K-T L1690634 1-

L 5006 CHIP COIL 0.022uH 2% LQW18AN22NG00D L1690884 1-

L 5007 M.RFC 0.015uH 2% C1608CB-15NG-RF L1691034 1-

Parts List

DESCRIPTION

VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.

REF.

LOT.

SIDE

LAY ADR.

SUB VCO Unit
