RF Unit (Lot. 1~7)
VX-8R/E Technical Supplement
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
D 1047 DIODE 1SV325(TPH3.F) G2070848 1- B a1
D 1048 DIODE 1SV325(TPH3.F) G2070848 1- B a1
D 1049 DIODE 1SV325(TPH3.F) G2070848 1- A B1
D 1050 DIODE DAN222M T2L G2070936 1- A B1
D 1051 DIODE 1SV325(TPH3.F) G2070848 1- A B1
D 1052 DIODE 1SS400G T2R G2070934 1- A B1
D 1053 DIODE 1SS400G T2R G2070934 1- A B2
D 1054 DIODE 1SS400G T2R G2070934 1- A B2
D 1055 DIODE 1SS400G T2R G2070934 1- B a1
D 1056 DIODE 1SS400G T2R G2070934 1- B a1
D 1057 DIODE 1SS385FV(TPL3.Z) G2071246 1- A B1
D 1058 DIODE 1SS400G T2R G2070934 1- A B1
D 1059 DIODE 1SS400G T2R G2070934 1- A B1
D 1060 DIODE DAN222M T2L G2070936 1- A A2
D 1061 DIODE DAP222M T2L G2070938 1- B a1
D 1062 DIODE DAN222M T2L G2070936 1- A A2
D 1063 DIODE DA221M T2L G2070940 1- B a2
D 1064 DIODE DA221M T2L G2070940 1- A B2
D 1065 DIODE DAN222M T2L G2070936 1- B a2
D 1067 DIODE DAN222M T2L G2070936 1- A A4
D 1068 DIODE DAN222M T2L G2070936 1- A A4
D 1069 DIODE JDS2S03S(TPH3.F) G2071062 1- A A2
D 1070 DIODE RB751G-40T2R G2071066 1- B c1
D 1071 DIODE RB751G-40T2R G2071066 1- A A1
D 1072 DIODE DA221M T2L G2070940 1- B b4
D 1073 DIODE
DA221M T2L G2070940 1- B b4
D 1074 DIODE DA221M T2L G2070940 1- B a3
D 1075 DIODE DA221M T2L G2070940 1- B a3
D 1076 DIODE DAN222M T2L G2070936 1- B c2
D 1077 DIODE RB751G-40T2R G2071066 1- A A1
D 1078 DIODE RB751G-40T2R G2071066 1- A A1
D 1079 DIODE RLS135 TE-11 G2070128 1- A A1
D 1080 DIODE 1SS314(TPH3.F) G2070122 1- B c1
D 1081 DIODE 1SV307(TPH3.F) G2070638 1- A A1
D 1082 DIODE RLS135 TE-11 G2070128 1- B c1
D 1083 DIODE 1SV307(TPH3.F) G2070638 1- B c1
D 1084 DIODE RLS135 TE-11 G2070128 1- A B1
D 1085 DIODE 1SV307(TPH3.F) G2070638 1- A B1
D 1086 DIODE DAN222M T2L G2070936 1- A B2
D 1087 DIODE 1SS385(TE85L.F) G2070880 1- B a2
D 1088 DIODE 1SS400G T2R G2070934 1- B a2
D 1089 DIODE 1SV271(TPH3.F) G2070476 1- A A1
D 1090 DIODE RB751G-40T2R G2071066 1- A A1
D 1091 DIODE 1SV271(TPH3.F) G2070476 1- A A1
D 1092 DIODE 1SV271(TPH3.F) G2070476 1- B c1
D 1093 DIODE 1SV271(TPH3.F) G2070476 1- B c1
D 1094 DIODE HN2D01FU(TE85R.F) G2070348 1- A A2
D 1095 DIODE DAN222M T2L G2070936 1- A A1
D 1097 SURGE ABSORBER EZAEG2A50AX Q9000868 1- A A1
D 1099 DIODE 1SS400G T2R G2070934 1- B c1
D 1100 DIODE 1SS385FV(TPL3.Z) G2071246 1- A B1
D 1101 DIODE 1SV308(TAPE) G2071202 1- A B1
D 1156 DIODE HVC359 TRF-E G2070708 1-
FB1001 CHIP COIL BLM21PG300SN1D L1690840 1- A B1
FB1002 CHIP COIL BLM21PG300SN1D L1690840 1- A A1
FB1003 CHIP COIL BLM21PG300SN1D L1690840 1- A C2
FB1004 CHIP COIL BLM21PG300SN1D L1690840 1- A C2
HS1001 HEATSINK PLATE (H029) RA1014100 1- B c2
J 1001 CONNECTOR DC-340-001-00 P0091507 1- A C2
J 1002 CONNECTOR AXK6F10345YP P0091378 1- A B3
