RF Unit (Lot. 1~7)
VX-8R/E Technical Supplement
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
L 1064 M.RFC 0.1uH 2% C1608CB-R10G-RF L1691045 1- B c2
L 1065 COIL E2 0.25-1.85-8.5T-L L0022576 1- A B2
L 1066 M.RFC 0.22uH LK1608 R22K-T L1690410 1- B c2
L 1067 COIL E2 0.3-0.9-3T-R L0022389 1- A A2
L 1068 COIL E2 0.4-1.3-2T-L L0022580 1- A A1
L 1069 COIL E2 0.3-1.0-6T-L L0022490 1- B c1
L 1070 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A A1
L 1071 M.RFC 1uH LK1608 1R0K-T L1690687 1- B c2
L 1072 COIL 0.0411uH F2309C L0023028 1- A A1
L 1074 COIL 0.022uH F2305C L0023024 1- A A1
L 1075 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- B b1
L 1076 COIL 0.022uH F2305C L0023024 1- A A1
L 1077 COIL 0.0411uH F2309C L0023028 1- B c1
L 1078 M.RFC 10uH LK1608 100K-T L1690689 1- A B1
L 1079 CHIP COIL 0.15uH LQW2BHNR15J03L L1690622 1- A B1
L 1080 COIL 0.0167uH F2304C L0023023 1- A A1
L 1081 COIL 0.0411uH F2309C L0023028 1- B c1
L 1082 COIL 0.0336uH F2307C L0023026 1- B c1
L 1083 COIL 0.022uH F2305C L0023024 1- A A1
L 1084 COIL E2 0.25-1.85-8.5T-L L0022576 1- A A1
L 1085 COIL E2 0.25-1.85-8.5T-L L0022576 1- A A1
L 1086 M.RFC 0.01uH TFL0510-10N L1690811 1- A A2
L 1087 COIL
0.0167uH F2304C L0023023 1- A A1
L 1088 COIL 0.0411uH F2309C L0023028 1- B c1
L 1089 COIL 0.0336uH F2307C L0023026 1- A A1
L 1090 M.RFC 0.022uH TFL0510-22N L1690815 1- A B2
L 1091 M.RFC 0.022uH TFL0510-22N L1690815 1- A B2
L 1092 M.RFC 10uH LK1608 100K-T L1690689 1- A B1
L 1093 M.RFC 0.68uH LK1608 R68K-T L1690416 1- A B1
L 1094 M.RFC 0.68uH LK1608 R68K-T L1690416 1- A B1
L 1095 M.RFC 0.15uH 2% C1608CB-R15G-RF L1691101 1- B b1
L 1096 M.RFC 0.022uH TFL0510-22N L1690815 1- A B2
L 1097 M.RFC 0.01uH TFL0510-10N L1690811 1- B b2
L 1098 M.RFC 0.022uH TFL0510-22N L1690815 1- B b2
P 1001 SPRING CONECTOR MS0038-40 S5000228 1-
P 1002 SPRING CONECTOR MS0038-40 S5000228 1-
P 1003 SPRING CONECTOR MS0038-40 S5000228 1-
Q 1001 TRANSISTOR 2SC5555ZD-TR G3355557 1- A B2
Q 1002 TRANSISTOR 2SC5555ZD-TR G3355557 1- B b1
Q 1003 TRANSISTOR 2SC5555ZD-TR G3355557 1- B c3
Q 1004 TRANSISTOR DTC144EM T2L G3070309 1- B c3
Q 1005 TRANSISTOR EMB3 T2R G3070303 1- A C2
Q 1006 TRANSISTOR EMB3 T2R G3070303 1- A C2
Q 1007 TRANSISTOR DTC144EM T2L G3070309 1- A C3
Q 1008 TRANSISTOR DTC144EM T2L G3070309 1- A C3
Q 1009 TRANSISTOR MT3S36FS(TE85L.F) G3070377 1- A B1
Q 1010 TRANSISTOR MT3S36FS(TE85L.F) G3070377 1- A C1
Q 1011 TRANSISTOR 2SC5555ZD-TR G3355557 1- A B1
Q 1012 IC LV24100LP-TLM-E G1094371 1- B c3
Q 1013 TRANSISTOR DTC144EM T2L G3070309 1- A C3
Q 1014 TRANSISTOR EMB10 T2R G3070302 1- A C2
Q 1015 TRANSISTOR 2SC5555ZD-TR G3355557 1- A B2
Q 1016 TRANSISTOR 2SC5555ZD-TR G3355557 1- A B2
Q 1017 IC MB15A01PFV1-G-BND-EFE1 G1092545 1- A B3
Q 1018 TRANSISTOR MT3S36FS(TE85L.F) G3070377 1- A C1
Q 1019 TRANSISTOR 2SC5555ZD-TR G3355557 1- A B2
Q 1020 TRANSISTOR 2SC5555ZD-TR G3355557 1- A B2
Q 1021 TRANSISTOR 2SC5555ZD-TR G3355557 1- B a1
Q 1022 TRANSISTOR 2SC5555ZD-TR G3355557 1- B a1
Q 1023 TRANSISTOR 2SC5555ZD-TR G3355557 1- A B1
