Yaesu VX-8R/E - Page 46

46
RF Unit (Lot. 1~7)
VX-8R/E Technical Supplement
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
R 1280 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- B a3
R 1281 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B a3
R 1282 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a3
R 1283 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A A1
R 1284 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c3
R 1285 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- B c3
R 1286 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c3
R 1287 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c3
R 1288 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c3
R 1289 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c3
R 1290 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c3
R 1291 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B c3
R 1292 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c3
R 1293 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c1
R 1294 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c3
R 1295 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c3
R 1296 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A2
R 1297 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c2
R 1298 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A3
R 1299 CHIP RES. 2.2M 1/16W 5% RMC1/16S 225JTH J24189065 1- A A3
R 1300 CHIP RES. 2.2M 1/16W 5% RMC1/16S 225JTH J24189065 1- A A3
R 1301 CHIP RES. 390k 1/16W 0.5% MCR01MZPD3903 J24189331 1- A A3
R 1302 CHIP RES. 4.7 1/16W 5% RMC1/16S 4R7JTH J24189066 1- A B3
R 1303 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- A B4
R 1304 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- A B1
R 1305 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- A B1
R 1306 CHIP RES. 56 1/16W 5% RMC1/16S 560JTH J24189010 1- B b1
R 1311 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A B2
R 1311 CHIP RES. 150 1/16W 5% RMC1/16S 151JTH J24189015 3- A B2
R 1312 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A B1
R 1313 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c3
R 1314 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A A1
R 1315 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A2
R 1316 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c4
R 1317 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c4
R 1318 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A B3
R 1319 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A A1
R 1320 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c2
S 1001 TACT SWITCH PT-036-B2S-T N5090158 1- A A 1
S 1002 TACT SWITCH PT-036-B2S-T N5090158 1- A A 2
S 1003 TACT SWITCH PT-036-B2S-T N5090158 1- A A 2
S 1004 TACT SWITCH PT-036-B2S-T N5090158 1- A A 3
TH1001 THERMISTOR ERTJ1VV473J G9090122 1- B c2
TH1002 THERMISTOR TN05-3M154JR G9090171 1-
X 1001 XTAL XV00117 11.7MHz 11.7MHZ H0103330A 1- A A3
XF1001 XTAL FILTER MFI47R 47.25MHZ H1102447 1- B a1
XF1002 XTAL FILTER MFI46R 46.35MHZ H1102448 1- A C2
INSULATOR SHEET RA0408300 1-
SHIELD SHEET (RF) RA1095800 1-
SHIELD SHEET (ANT) RA109330A 3-
SHEET (13X3.5) RA1100300 4-
