RF-2 Unit (Lot.8~)
VX-8R/E and VX-8DR Technical Supplement
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
Q 8073 TRANSISTOR 2SC5658 T2L Q/R G3356588 8- B b4
Q 8074 TRANSISTOR 2SC5658 T2L Q/R G3356588 8- B a3
Q 8075 TRANSISTOR DTC144EM T2L G3070309 8- A A1
Q 8076 TRANSISTOR 2SC5374-TL G3353748 8- A A2
Q 8077 TRANSISTOR CPH6102-TL G3070223 8- A C2
Q 8078 TRANSISTOR EMB3 T2R G3070303 8- A A3
Q 8079 TRANSISTOR UMW1 TR G3070078 8- A C1
Q 8080 TRANSISTOR 2SA2029 T2L Q/R G3120298 8- A A2
Q 8081 TRANSISTOR EMB3 T2R G3070303 8- B b2
Q 8082 TRANSISTOR EMG2 T2R G3070304 8- A A3
Q 8083 TRANSISTOR DTC144EM T2L G3070309 8- B b2
Q 8084 TRANSISTOR 2SC5658 T2L Q/R G3356588 8- B b4
Q 8085 TRANSISTOR 2SC5658 T2L Q/R G3356588 8- B a3
Q 8086 IC TC74VHC595FK(EL,K) G1094552 8- B b2
Q 8087 IC TC74VHC595FK(EL,K) G1094552 8- B b2
Q 8088 TRANSISTOR DTC144EM T2L G3070309 8- B c1
Q 8089 TRANSISTOR EMD6-T2R G3070346 8- B c2
Q 8090 TRANSISTOR DTC144TE-TL G3070280 8- B c3
Q 8091 FET HN1J02FU(TE85L.F) G3070221 8- B c3
Q 8092 TRANSISTOR DTC144EM T2L G3070309 8- B c3
Q 8093 TRANSISTOR EMB10 T2R G3070302 8- A A3
Q 8094 TRANSISTOR 2SA2029 T2L Q/R G3120298 8- A A2
Q 8095 TRANSISTOR EMG2 T2R G3070304 8- A A2
Q 8096 IC NJU7007F3-TE1 G1093617 8- A A3
Q 8097 IC BA2902KN G1094201 8- B c2
Q 8098 IC NJU7007F3-TE1 G1093617 8- A A3
Q 8099 IC XC6371A650DR G1094584 8- A C2
Q 8100 TRANSISTOR 2SC5555ZD-TR G3355557 8- B b1
Q 8101 TRANSISTOR 2SC5555ZD-TR G3355557 8- A B1
Q 8102 FET 2SK3541 T2L G3835417 8- A B1
Q 8103 TRANSISTOR DTC144EM T2L G3070309 8- B c3
Q 8104 FET 2SK3541 T2L G3835417 8- A A2
Q 8105 FET 2SK3541 T2L G3835417 8- B c4
Q 8106 TRANSISTOR DTC144EM T2L G3070309 8- B c2
Q 8107 TRANSISTOR DTC144EM T2L G3070309 8- B c2
Q 8108 TRANSISTOR UMD2N TR G3070076 8- A A3
Q 8109 TRANSISTOR UMD2N TR G3070076 8- B a3
Q 8110 FET SSM3J36FS G3070433 24- A A3
Q 8110 FET RZM002P02 G3070432 32- A A3
R 8001 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 8- B c3
R 8002 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 8- A A3
R 8003 CHIP RES. 22k 1/16 W 5 % RMC1/16S 223JTH J24189041 8- A B2
R 8004 CHIP RES. 15 1 /1 6W 5 % RMC1/16S 150JTH J24189003 8- A B2
R 8005 CHIP RES. 56k 1/16 W 5 % RMC1/16S 563JTH J24189046 8- B b1
R 8006 CHIP RES. 56 1 /1 6W 5 % RMC1/16S 560JTH J24189010 8- B b1
R 8007 CHIP RES. 2.2M 1/16W 5% RMC1/16S 225JTH J24189065 8- A A3
R 8008 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 8- B c3
R 8009 CHIP RES. 1.8k 1/16W 5% RMC1/16S 182JTH J24189028 8- B c3
R 8010 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 8- B c3
R 8011 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 8- B a4
R 8012 CHIP RES. 47k 1/16 W 5 % RMC1/16S 473JTH J24189045 8- A B1
R 8014 CHIP RES. 47 1 /1 6W 5 % RMC1/16S 470JTH J24189009 8- A C1
R 8015 CHIP RES. 47k 1/16 W 5 % RMC1/16S 473JTH J24189045 8- A C1
R 8016 CHIP RES. 22 1 /1 6W 5 % RMC1/16S 220JTH J24189005 8- A B2
R 8017 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 8- A B2
R 8018 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 8- A A2
R 8019 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 8- A B2
R 8020 CHIP RES. 22 1 /1 6W 5 % RMC1/16S 220JTH J24189005 8- A B2
R 8021 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 8- A B2
R 8022 CHIP RES. 56k 1/16 W 5 % RMC1/16S 563JTH J24189046 8- B b1
