72
RF-2 Unit (Lot.8~)
VX-8R/E and VX-8DR Technical Supplement
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE
LAY ADR.
R 8301 CHIP RES. 390k 1/16W 0.5% MCR01MZPD3903 J24189331 8- A A3
R 8302 CHIP RES. 4.7 1/1 6W 5 % RMC1/16S 4R7JTH J24189066 8- A C2
R 8303 CHIP RES. 22 1 /1 6W 5 % RMC1/16S 220JTH J24189005 8- A C3
R 8304 CHIP RES. 68 0 1 /1 6W 5 % RMC1/16S 681JTH J24189023 8- A B1
R 8305 CHIP RES. 68 0 1 /1 6W 5 % RMC1/16S 681JTH J24189023 8- A B1
R 8306 CHIP RES. 56 1 /1 6W 5 % RMC1/16S 560JTH J24189010 8- B b1
R 8311 CHIP RES. 15 0 1 /1 6W 5 % RMC1/16S 151JTH J24189015 8- A B2
R 8312 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 8- A B1
R 8313 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 8- B c3
R 8314 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 8- A A1
R 8315 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 8- A A2
R 8316 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 8- B c4
R 8317 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 8- B c4
R 8318 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 8- A B3
R 8319 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 8- A A1
R 8320 CHIP RES. 22k 1/16 W 5 % RMC1/16S 223JTH J24189041 8- B c2
R 8321 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 16- A A3
R 8322 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 16- A B3
R 8324 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 24- A A3
R 8325 CHIP RES. 6.8M 1/16W 5% TSR16GJ685V J24189502 24-31 A A3
S 8001 TACT SWITCH PT-036-B2S-T N5090158 8- A A 1
S 8002 TACT SWITCH PT-036-B2S-T N5090158 8- A A 2
S 8003 TACT SWITCH PT-036-B2S-T N5090158 8- A A 2
S 8004 TACT SWITCH PT-036-B2S-T N5090158 8- A A 3
TH8001 THERMISTOR ERTJ1VV473J G9090122 8- B c2
TH8002 THERMISTOR TN05-3M154JR G9090171 8- B c2
X 8001 XTAL XV00117 11.7MHz 11.7MHZ H0103330A 8- A A3
XF8001 XTAL FILTER MFI47R 47.25MHZ H1102447 8- B a1
XF8002 XTAL FILTER MFI46R 46.35MHZ H1102448 8- A C2
INSULATOR SHEET RA0408300 8-15
SHIELD SHEET (ANT) RA109330A 1-
CU TAPE (H029M) RA1121600 8-15
SHEET (10X9.5) RA1127600 8
SHEET (10X9.5) RA112760A 9-
