82
CNTL Unit (Lot.1~7)
VX-8R/E Technical Supplement
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
Q 2055 IC CMX865AE4 G1094617 1- B b1
Q 2056 IC TC74VHC595FK(EL,K) G1094552 1- B b4
Q 2057 TRANSISTOR DTC144EM T2L G3070309 1- B b2
Q 2058 TRANSISTOR UMH4N TN G3070399 1- B b1
Q 2059 TRANSISTOR DTC144EM T2L G3070309 1- B c1
Q 2060 TRANSISTOR DTC144EM T2L G3070309 1- B c2
Q 2061 TRANSISTOR 2SC5658 T2L Q/R G3356588 1- B b1
Q 2062 TRANSISTOR 2SC5658 T2L Q/R G3356588 1- B b1
Q 2063 IC TAR5S33U(TE85L.F) G1094549 1- B b1
Q 2064 FET MCH6305-TL G3070301 1- B b1
Q 2065 TRANSISTOR 2SA2029 T2L Q/R G3120298 1- B b4
R 2001 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 1- A A2
R 2002 CHIP RES. 15k 1/16 W 5 % RMC1/16S 153JTH J24189039 1- B a2
R 2004 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A A2
R 2005 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 1- A A1
R 2006 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A A1
R 2007 CHIP RES. 47k 1/16 W 5 % RMC1/16S 473JTH J24189045 1- B c1
R 2008 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a4
R 2009 CHIP RES. 22k 1/16 W 5 % RMC1/16S 223JTH J24189041 1- B b4
R 2010 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B a2
R 2011 CHIP RES. 22k 1/16 W 5 % RMC1/16S 223JTH J24189041 1- B a2
R 2012 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B b2
R 2014 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 1- A C1
R 2015 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 1- A C2
R 2016 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 1- A C2
R 2017 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A C2
R 2018 CHIP RES. 47 0 1 /1 6W 5 % RMC1/16S 471JTH J24189021 1- B a2
R 2019 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 2020 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 2021 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 2022 CHIP RES. 22k 1/16 W 5 % RMC1/16S 223JTH J24189041 1- B b4
R 2023 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B b4
R 2024 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B a2
R 2025 CHIP RES. 22k 1/16 W 5 % RMC1/16S 223JTH J24189041 1- B a2
R 2026 CHIP RES. 82k 1/16 W 5 % RMC1/16S 823JTH J24189048 1- B a2
R 2027 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B a2
R 2028 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 2029 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A C2
R 2030 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A C2
R 2031 CHIP RES. 22 1 /2 W 5 % RMC1/2 220JCTP J24275220 1- A C3
R 2032 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A C2
R 2033 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A C2
R 2034 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A C2
R 2035 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A C2
R 2036 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A C2
R 2037 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A C2
R 2038 CHIP RES. 47k 1/16 W 5 % RMC1/16S 473JTH J24189045 1- B b1
R 2039 CHIP RES. 47k 1/16 W 5 % RMC1/16S 473JTH J24189045 1- B b1
R 2040 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 2041 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b4
R 2042 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 2043 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2044 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A C2
R 2045 CHIP RES. 20k 1/16 W 5 % RMC1/16S 203JTH J24189455 1- A C2
R 2046 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- A C2
R 2047 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A C2
R 2048 CHIP RES. 15k 1/16 W 5 % RMC1/16S 153JTH J24189039 1- A C2
R 2049 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A C2
R 2050 CHIP RES. 20k 1/16 W 5 % RMC1/16S 203JTH J24189455 1- A C2
R 2051 CHIP RES. 47 1 /1 6W 5 % RMC1/16S 470JTH J24189009 1- A C1
