CNTL Unit (Lot.1~7)
VX-8R/E Technical Supplement
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
R 2174 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A C3
R 2175 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A C2
R 2176 CHIP RES. 33k 1/16 W 5 % RMC1/16S 333JTH J24189043 1- A C3
R 2177 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B c1
R 2178 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B c1
R 2179 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B a4
R 2181 CHIP RES. 1M 1/16 W 5 % RMC1/16S 105JTH J24189061 1- B b2
R 2183 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c2
R 2184 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c2
R 2185 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2186 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2187 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B b2
R 2189 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B b1
R 2191 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B b1
R 2193 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B a4
R 2194 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B c1
R 2196 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2197 CHIP RES. 47k 1/16 W 5 % RMC1/16S 473JTH J24189045 1- B b1
R 2198 CHIP RES. 22k 1/16 W 5 % RMC1/16S 223JTH J24189041 1- B b4
R 2199 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B b4
R 2200 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a1
R 2201 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B b1
R 2202 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B b4
R 2203 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 1- B a4
R 2204 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b4
R 2205 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B b4
R 2206 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b4
R 2210 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 1- B c2
R 2212 CHIP RES. 47k 1/16 W 5 % RMC1/16S 473JTH J24189045 1- B b1
R 2213 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2214 CHIP RES. 47k 1/16 W 5 % RMC1/16S 473JTH J24189045 1- B b1
R 2215 CHIP RES. 47k 1/16 W 5 % RMC1/16S 473JTH J24189045 1- B b1
R 2216 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 1- B b1
R 2217 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B b2
R 2218 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B a2
R 2219 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B a2
R 2220 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 1- B b2
R 2221 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 1- B b2
R 2222 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- B c1
R 2223 CHIP RES. 68 0 1 /1 6W 5 % RMC1/16S 681JTH J24189023 1-
R 2224 CHIP RES. 3.3M 1/16W 5% RMC1/16S 335JTH J24189324 1-
R 2225 CHIP RES. 0 1/ 16 W 5 % RMC1/16 000JATP J24185000 1-
R 2226 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1-
R 2226 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 5-
R 2227 CHIP RES. 0 1/ 16 W 5 % RMC1/16S JPTH J24189070 5-
S 2001 ROTARY ENCODER TP70N1062E20 RY-8540 Q9000896 1- B a1
S 2002 TACT SWITCH SKRWAEE030 N5090156 1- A A1
S 2003 TACT SWITCH EVQPQHB55 N5090103 1- A A 2
S 2004 TACT SWITCH SKRWAEE030 N5090156 1- A A2
S 2005 TACT SWITCH EVQPQHB55 N5090103 1- A A 3
S 2006 TACT SWITCH EVQPQHB55 N5090103 1- A A 3
S 2007 TACT SWITCH EVQPQHB55 N5090103 1- A A 4
S 2008 TACT SWITCH EVQPQHB55 N5090103 1- A A 4
S 2009 TACT SWITCH EVQPQHB55 N5090103 1- A A 4
S 2010 TACT SWITCH EVQPQHB55 N5090103 1- A A 4
S 2011 TACT SWITCH EVQPQHB55 N5090103 1- A B4
S 2012 TACT SWITCH EVQPQHB55 N5090103 1- A B4
S 2013 TACT SWITCH EVQPQHB55 N5090103 1- A A 4
S 2014 TACT SWITCH EVQPQHB55 N5090103 1- A A 4
S 2015 TACT SWITCH EVQPQHB55 N5090103 1- A B4
