Yaesu VX-8R/E - Page 98

98
CNTL-2 Unit (Lot.8~)
VX-8R/E and VX-8DR/E Technical Supplement
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
Q 9042 TRANSISTOR DTC144EM T2L G3070309 8- B b3
Q 9043 TRANSISTOR DTC144EM T2L G3070309 8- B c3
Q 9044 TRANSISTOR DTC144EM T2L G3070309 8- B c3
Q 9045 FET 2SK3541 T2L G3835417 8- B c1
Q 9046 FET 2SK3541 T2L G3835417 8- B b1
Q 9047 FET 2SK3541 T2L G3835417 8- B b1
Q 9048 TRANSISTOR DTC144TE-TL G3070280 8- B b3
Q 9049 TRANSISTOR DTC144EM T2L G3070309 8- B c3
Q 9050 TRANSISTOR DTC144TE-TL G3070280 8- B b3
Q 9051 IC BU2502MUV G1094586 8- B a4
Q 9052 TRANSISTOR DTC144EM T2L G3070309 8- B a3
Q 9053 TRANSISTOR DTC143ZE TL G3070102 8- A C3
Q 9054 IC CMX589AD5 G1094597 8- B c2
Q 9055 IC CMX865AE4 G1094617 8- B b1
Q 9056 IC TC74VHC595FK(EL,K) G1094552 8- B b4
Q 9057 TRANSISTOR DTC144EM T2L G3070309 8- B b2
Q 9058 TRANSISTOR UMH4N TN G3070399 8- B b1
Q 9059 TRANSISTOR DTC144EM T2L G3070309 8- B c1
Q 9060 TRANSISTOR DTC144EM T2L G3070309 8- B c2
Q 9061 TRANSISTOR 2SC5658 T2L Q/R G3356588 8- B b1
Q 9062 TRANSISTOR 2SC5658 T2L Q/R G3356588 8- B b1
Q 9063 IC TAR5S33U(TE85L.F) G1094549 8- B b1
Q 9064 FET MCH6305-TL G3070301 8- B b1
Q 9065 TRANSISTOR 2SA2029 T2L Q/R G3120298 8- B b4
Q 9067 TRANSISTOR CPH6102-TL G3070223 8- B b4
Q 9068 TRANSISTOR UMW1 TR G3070078 8- B b4
Q 9069 FET 2SK3541 T2L G3835417 24- B a2
R 9001 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 1- A A2
R 9002 CHIP RES. 15k 1/16 W 5 % RMC1/16S 153JTH J24189039 8- B a2
R 9004 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 8- A A2
R 9005 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 8- A A1
R 9006 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 8- A A1
R 9007 CHIP RES. 47k 1/16 W 5 % RMC1/16S 473JTH J24189045 8- B c1
R 9008 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 8- B a4
R 9009 CHIP RES. 22k 1/16 W 5 % RMC1/16S 223JTH J24189041 8- B b4
R 9010 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 8- B a2
R 9011 CHIP RES. 22k 1/16 W 5 % RMC1/16S 223JTH J24189041 8- B a2
R 9012 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 8- B b2
R 9014 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 8- A C1
R 9015 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 8- A C2
R 9016 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 8- A C2
R 9017 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 8- A C2
R 9018 CHIP RES. 47 0 1 /1 6W 5 % RMC1/16S 471JTH J24189021 8- B a2
R 9019 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 8- B a2
R 9020 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 8- B b1
R 9021 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 8- B b1
R 9022 CHIP RES. 22k 1/16 W 5 % RMC1/16S 223JTH J24189041 8- B b4
R 9023 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 8- B b4
R 9024 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 8- B a2
R 9025 CHIP RES. 22k 1/16 W 5 % RMC1/16S 223JTH J24189041 8- B a2
R 9026 CHIP RES. 82k 1/16 W 5 % RMC1/16S 823JTH J24189048 8- B a2
R 9027 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 8- B a2
R 9028 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 8- B b1
R 9029 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 8- A C2
R 9030 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 8- A C2
R 9031 CHIP RES. 22 1 /2 W 5 % RMC1/2 220JCTP J24275220 8- A C3
R 9032 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 8- A C2
R 9033 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 8- A C2
R 9034 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 8- A C2
R 9035 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 8- A C2
