Please ensure that alignment
tool is flat against the door
as screws are tightened. This
ensures the motor is aligned
correctly.
Aligning Handle
(09)
INSIDE
OUTSIDE
1
2 3
4
5
6
Ensure exterior handle and fixing
plate are parallel before finally
tightening screws.
