INSIDE
INSIDE
7
Measuring Your Door
Measure the thickness of the door to select the correct fixing pack.
44-50mm
58-65mm
70mm
Door thickness
Door thickness Door thickness
Measure the distance between the centre of the lock
and the inside of the door to select the correct tailbar.
INSIDE
INSIDE
