Load Wheels 100 YRM 1015
Painting Instructions
WARNING
Always use sol
vents and paints in an area with ven-
tilation. DO N
OT use solvents or paints near heat or
fire.
Cleaning sol
vents can be flammable and toxic and
can cause ski
n irritation. Wear protection for eyes
and skin. Whe
n using cleaning solvents, always
follow the re
commendations of the manufacturer.
1. Remove all di
rt from the surface to be painted.
Clean the are
a to be painted using a solvent for
painted sur
faces. Remove all oil and grease.
2. Remove the top surface of paint and all rust from
the metal using sandpaper. Paint all metal sur-
faces where the paint is completely removed using
primer. Apply the primer before applying the color
paint.
3. Protect all surfaces that will not be painted. DO
NOT paint cylinder rods, cables, labels, plates, or
controls.
4. Paint all the surfaces the original color, using Yale
®
paint. Follow the directions on the container.
Load Wheels
REMOVE
WARNING
Put blocks under both forks and on both sides of
the drive tire. The blocks must prevent the lift truck
from falling and causing personal injury or property
damage.
1. Use the lift button to raise the lift truck to its maxi-
mum height.
2. Put blocks under both forks and on both sides of the
drive tire. See the section How to Put a Lift Truck
on Blocks in the Periodic Maintenance manual.
3. Drive the r
oll pin retaining the axle shaft to the rear
axle link
out of the link and axle.
4. Lower the h
oist cylinder using the lower button.
This will
raise the load wheels off the floor.
5. Move the k
ey to the OFF position. Disconnect the
battery.
Remove the battery.
6. Remove th
e axle shaft. Remove bearings and load
wheel fro
m the link. It may be necessary to drive
the beari
ng out of the wheel. Drive the bearing out
from the o
pposite sides. See Figure 4.
6
