Legend for Figure 5
A. STANDARD TRUCK B. RETAIL DELIVERY TRUCK
1. CONTROL HANDLE ARM
2. CONTROL HEAD ASSEMBLY
3. EMERGENCY POWER DISCONNECT
4. KEY SWITCH
5. DISPLAY - BATTERY INDICATOR/HOURMETER
6. DELIVERY HANDLE ARM
7. DELIVERY CONTROL HEAD ASSEMBLY
8. MOVABLE LOAD BACKREST
Model Description
14
