Table 1. Instruments and Controls (See Figure 5) (Continued)
Item
No.
Item Function
f Lift Button Press the button to raise the forks. Release the button to stop lifting. If the
truck is trying to lift too much weight, the hydraulic system will go into
bypass and the controller will shut off the hydraulic motor. The lift function is
timed, if held for more than seven seconds, the lift function will stop.
If the horn sounds when the lift button is pressed, this indicates that the bat-
tery is discharged below 70% and needs changed or recharged. Lift is disa-
bled at 80% discharge of the battery.
Your truck may be configured with the optional SMART LIFT™. For trucks
equipped with this feature, the option can be activated and deactivated by
simultaneous selection of lift and lower buttons on either left or right hand
sides. To activate the feature, select lift and lower simultaneously. The vehi-
cle horn will sound once to indicate feature is active. To deactivate the fea-
ture, simultaneously select lift and lower. The vehicle horn will sound twice.
To initiate lift, briefly select the lift button. The truck will lift to a programmed
height. Confirm that the truck and load are clear of obstacles. Upon initiation
of forward travel, lift will complete. Lift function can be interrupted by selec-
tion of the lower button.
Model Description
23

Yale MPB045VG Specifications

General

Model	MPB045VG
Category	Forklifts
Power Source	Electric
Load Capacity	4500 lbs
Battery Voltage	24V
Battery Capacity	375 Ah
