Table 1. Instruments and Controls (See Figure 5) (Continued)
Item
No.
Item Function
3 Emergency Power Disconnect The emergency power disconnect is located on top of the cowl. Push the
button to interrupt power supply.
4 Key Switch The key switch is located on the operator's display panel. The key switch
has two positions: O and I. No truck functions are enabled when the key is
the O (OFF) position. When the key is rotated clockwise to the I (ON) posi-
tion, power is applied.
NOTE: Always raise the control handle or delivery handle to the full upright
position and move the key to the OFF position when leaving the lift truck.
Model Description
24
