10
Mounting Devices
4
Smart Hub 2.0 Mounting
The Smart Hub can be free standing, either vertically or
horizontally on a at surface with access to mains socket
and broadband internet router.
It is also suitable for wall mounting. Using the two holes on
the mounting back plate, mark the position of the holes.
Drill two holes and x with the screws and plugs provided.
Hook the Smart Hub onto the plate.
Check Accessories Range
1.) Place each device in the location where you wish to
mount them.
Before mounting each device. Please check the system
with a simple range test.
Login to your Yale Home App. Select “Tests”, “Device List”
then select “Walk Test”.
Hold the devices in the desired location and press the Test/
Learn button on the accessories. (see page 9)
If the sensor signal reached the Smart Hub, it will show in
the device list on your app.
When you are happy that all your devices can
communicate with the Smart Hub, please proceed to
mounting the accessories.
Before you mount a device use the device settings in the
Smart Living Home app to bypass the device and disable
the tamper alert. After the device is fully in place don’t
forget to disable the bypass.
Mounting the PIR
Mounting the Key Pad
