Yale YRD420-F

26
P/N YRD420-KD-F Rev A
Using Your Lock
Exterior Keypad
To lock your door
Press
Touch
To unlock your door
• With fingerprint*
• With entry code
Press
Enter entry code
Press
Interior Lock
1. Exterior LED Indicator
2. Wake / One-Touch Locking /
Fingerprint Scanner
3. Warnings / Menu
4. Submit Entry Code
5. Thumbturn
6. Passage Button
7. Interior LED Indicator
1
3 4
2 5
67
* Make sure that you’re using a registered
finger, and that it’s clean and dry.
