IGNITION SYSTEM
8-5
EAS27140
TROUBLESHOOTING
The ignition system fails to operate (no spark or intermittent spark).
TIP
● Before troubleshooting, remove the following part(s):
1.Seat
2.Fuel tank
3.Side cowling
1. Check the fuses.
(Main and ignition)
Refer to
“CHECKING THE FUSES” on
page 8-153
.
NG
→
Replace the fuse(s).
OK ↓
2. Check the battery.
Refer to “CHECKING AND CHARG-
ING THE BATTERY” on page 8-154 .
NG →
●
Clean the battery terminals.
●
Recharge or replace the battery.
OK ↓
3. Check the spark plugs.
Refer to
“CHECKING THE SPARK
PLUGS” on page 3-4
.
NG
→
Re-gap or replace the spark plugs.
OK ↓
4. Check the spark plug caps.
Refer to
“CHECKING THE SPARK
PLUG CAPS” on page 8-160
.
NG
→
Replace the spark plug caps.
OK ↓
5. Check the ignition coils.
Refer to
“CHECKING THE IGNITION
COIL” on page 8-160
.
NG
→
Replace the ignition coils.
OK ↓
6. Check the crankshaft position sen-
sor.
Refer to
“CHECKING THE CRANK-
SHAFT POSITION SENSOR” on page
8-161
.
NG
→
Replace the crankshaft position sensor.
OK ↓
7. Check the main switch.
Refer to
“CHECKING THE
SWITCHES” on page 8-149
.
NG
→
Replace the main switch.
OK ↓
8. Check the engine stop switch.
Refer to
“CHECKING THE
SWITCHES” on page 8-149
.
NG
→
Replace the right handlebar switch.
OK ↓
9. Check the neutral switch.
Refer to
“CHECKING THE
SWITCHES” on page 8-149
.
NG
→
Replace the neutral switch.
OK ↓
10.Check the sidestand switch.
Refer to
“CHECKING THE
SWITCHES” on page 8-149
.
NG
→
Replace the sidestand switch.
❄❉❂❋✫❇ !  

Yamaha 2009 Diversion XJ6S Specifications

General

Year	2009
Manufacturer	Yamaha
Model	Diversion XJ6S
Category	Motorcycle
Displacement	600 cc
Bore x Stroke	65.5 mm x 44.5 mm
Compression Ratio	12.2:1
Fuel System	Fuel Injection
Ignition	TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Rear Suspension	Swingarm
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Length	2, 120 mm
Width	770 mm
Height	1, 210 mm
Seat Height	785 mm
Wheelbase	1, 440 mm
Ground Clearance	140 mm
Fuel Capacity	17.3 liters
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-cylinder
Power	77.5 hp @ 10, 000 rpm
Front Brake	Dual disc
Rear Brake	245 mm disc
