FUEL PUMP SYSTEM
8-87
EAS27570
TROUBLESHOOTING
If the fuel pump fails to operate.
TIP
● Before troubleshooting, remove the following part(s):
1.Seat
2.Fuel tank
1. Check the fuses.
(Main, ignition and fuel injection sys-
tem)
Refer to
“CHECKING THE FUSES” on
page 8-153
.
NG
→
Replace the fuse(s).
OK ↓
2. Check the battery.
Refer to
“CHECKING AND CHARG-
ING THE BATTERY” on page 8-154
.
NG
→
●
Clean the battery terminals.
●
Recharge or replace the battery.
OK ↓
3. Check the main switch.
Refer to
“CHECKING THE
SWITCHES” on page 8-149
.
NG
→
Replace the main switch.
OK ↓
4. Check the engine stop switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149 .
NG → Replace the right handlebar switch.
OK ↓
5. Check the fuel injection system
relay.
Refer to
“CHECKING THE RELAYS”
on page 8-157
.
NG
→
Replace the relay unit.
OK ↓
6. Check the fuel pump.
Refer to
“CHECKING THE FUEL
PRESSURE” on page 7-9
.
NG
→
Replace the fuel pump.
OK ↓
7. Check the entire fuel pump system
’
s
wiring.
Refer to
“CIRCUIT DIAGRAM” on page
8-83
.
NG
→
Properly connect or repair the fuel pump
system
’
s wiring.
OK ↓
Replace the ECU.
❄❉❂❋✫❇ ✫✪  

Yamaha 2009 Diversion XJ6S Specifications

General

Year	2009
Manufacturer	Yamaha
Model	Diversion XJ6S
Category	Motorcycle
Displacement	600 cc
Bore x Stroke	65.5 mm x 44.5 mm
Compression Ratio	12.2:1
Fuel System	Fuel Injection
Ignition	TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Rear Suspension	Swingarm
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Length	2, 120 mm
Width	770 mm
Height	1, 210 mm
Seat Height	785 mm
Wheelbase	1, 440 mm
Ground Clearance	140 mm
Fuel Capacity	17.3 liters
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-cylinder
Power	77.5 hp @ 10, 000 rpm
Front Brake	Dual disc
Rear Brake	245 mm disc
