Yamaha 85AED - Page 103

3-15
REMOTE CONTROL TYPES AND APPLICATIONS
Quad engine application
208 (8.19)
149 (5.87)
41
(1.61)
116 (4.57)
100 (3.93)
ECM for C-PORT/ C-STBD
6 (0.24)
132 (5.20)
145 (5.71)
105 (4.13)
102 (4.02)
172 (6.77)
Template for RC unit
6 (0.24)
R10 (0.39)
94 (3.70)
99 (3.90)
115 (4.53)
37
(1.48)
304 (12)
14
(0.55)
71 (2.80)
812 (32)
87 (3.43)
66 (2.60)
Template for PTT SW
RLG
GW P
XXX
LY
Or
* ECM wire harness length:
Approx. 1.5 m (5 ft)
mm (in.)
