4-24
STEERING FRICTION CONTENTS
For detailed installation information, see the instruction manual packed in the tiller handle kit and/or
the steering friction kit.
To be continued.
General torque table
Nm kgf•m lb•ft
M10 locknut 4 0.4 3
M6 bolt 8 0.8 6
M5 bolt 5 0.5 4
Part No.
6AH-42508-01 (for manual tilt)
6AH-42508-11 (for power tilt)
Global model F9.9H F15C F20B F20C
US/CA model F15A F20A
Part No. 65W-42508-00
Global model F25D FT25F
US/CA model
F25A/B
T25A
3 Nm, 0.3 kgf•m, 2.2 lb•ft
Part No. 67C-42508-04
Global model F30B F40F
US/CA model F30A F40A
Part No. 68T-42508-02
Global model F8C FT8D
US/CA model F8A
