Yamaha 85AED - Meter Harness

5-33
WIRE HARNESSES
METER HARNESS
For analog meter
For digital meter
Part No. Length (L) Remarks
6Y5-83553-00 2.5 m (8 ft)
For all models
except V4/V6
Part No. Length (L) Remarks
6Y5-8350U-00 200 mm (8 in)
Part No. Length (L) Remarks
6Y5-83553-10 5 m (16 ft)
For pre-mixed
model
B
Y
L
G
LY
G
B
Y
(10A)
YY
( L )
( L )
B
G
Y
B
G
Y
( L )
( L )
G
G
Y
G
G/R
G/R
B
Part No. Length (L) Remarks
6Y5-83553-N0 2.5 m (8 ft)
For twin engine
application
Part No. Length (L) Remarks
6Y5-83553-M0 2.5 m (8 ft)
For single engine
application
Part No. Length (L) Remarks
6Y5-83553-20 2.5 m (8 ft) L/H model
Part No. Length (L) Remarks
6Y5-8356N-00 1.5 m (5 ft) Extension harness
