Yamaha 85AED - Fuel Pipes (Typical); Primary Pump (Typical)

9-8
FUEL PIPES (TYPICAL)
PRIMARY PUMP (TYPICAL)
No. Part No. Hose inside diameter Length (L) Remarks
1 6Y1-24306-55 6 mm (0.24 in) 3 m (10 ft) For small engines
2 6YK-24306-64 8 mm (0.31 in) 3 m (10 ft) US/CA meeting with EPA regulations
3 6YK-24306-04 6 mm (0.24 in) 3 m (10 ft) For kerosene models
Part No. Hose inside diameter Remarks
6YK-24360-73 8 mm (0.31 in) Meeting with EPA regulations, Above F75
6YL-24360-51 6 mm (0.24 in)
(L)(L)
(L)
12
3
