5-27
HOUR METER
The hour meter provides the operator with useful at-a-glance information.
It monitors the number of hours a motor has been used since original installation.
* The transaction of time count when the engine is stopped differs on each hour meter and YDIS, therefore
the elapsed time is not always equal on their equipment.
HOUR METER APPLICATIONS
HOUR METER DIMENSIONS
Ref. No. Description Part No. Applicable model
1 Mechanical 6Y5-83504-01
All electrical start models
2
Digital, Black panel 6Y7-83504-00
Digital, White panel 6Y7-83504-10
7.5 (0.3)
34.5 (1.36)
31.5 (1.24)
52 (2.05)
62 (2.44)
60 (2.36)
11 (0.43)
71.5 (2.81)
33 (1.3)
52 (2.05)
Mechanical Digital
mm (in.)mm (in.)
