3-31
REMOTE SWITCH TYPES AND APPLICATIONS
STATION SELECTOR SWITCH
Ref. No. Part No. Description
1 6X6-82570-A0 For Digital Network System (6Y8), Dual station
2 6X6-82570-B0 For Digital Network System (6Y9), Dual station, Single/Twin/Triple engine application
3 6X6-82570-L0 For Digital Network System (6Y9), Dual station, Quad engine application only
1
2
3
mm (in.)
B B B
GGG
66 (2.60)
49 (1.93)
68 (2.68)
51 (2.01)
5.5 (0.22)
110 (4.33)
100 (3.94)
GGG
BB
B
37.2
(1.46)
22
(0.87)
61.5 (2.42) 12 (0.47)
55 (2.17)
38.1 (1.5)
50 (1.97)
33.4 (1.31)
5.6 (0.22)
38.4
(1.51)
200 (7.87)
61.5 (2.42)
12
(0.47)
55 (2.17)
50 (1.97)
38.1 (1.5)
33.4 (1.31)
5.6 (0.22)
38.4
(1.51)
Y
Br
