DIGITAL ELECTRONIC REMOTE CONTROL WIRE HARNESS
CONVERSION HARNESS P
Used to connect between 2nd helm new DEC and 2nd helm previous start/stop SW. (Triple engine
application)
Part No. Length (L) Remarks
6X6-8258A-P0 240 mm (9 in)
For 2nd station helm, Triple
engine application
XPBr
XPBr
Y
Y
X P Br Y
Y W Br
XBP
Y W Br
XBP
Y W Br
XBP
WWW
BBB
(L)
P
S
C
To 2nd helm
DEC
To 2nd helm
SW panel
