OUTBOARD MOTOR DIMENSIONS

CLAMP BRACKET DIMENSIONS

Global model 6C 8C

US/CA model

Manual tilt

Symbol mm (in.) Symbol mm (in.) Symbol mm (in.) Symbol mm (in.)

B1 — B8 — C1 22 (0.9) D1 —

B2 — B9 — C2 55 (2.2) D2 —

B3 — B10 — C3 — D3 —

B4 — B11 56 (2.2) D4 —

B5 75 (3.0) B12 50 (2.0)

B6 164.3 (6.5)

B7 —

C/L

B11

B12
