2-7
2014 PROPELLER APPLICATIONS
STANDARD PROPELLER
8 ps
6 – 9.9 ps
9.9 – 15 ps
* Use the thrust washer (6B8-45987-00) for kerosene model, avoiding propeller damper damage.
9.9 – 20 ps
Global model E8D EK8D
US/CA model
Blade Dia. (in) Pitch (in) Mark Material Part number Remarks
3 7 1/4 5 C Aluminum 655-45949-00 Fitted with shear pin
3 9 5 3/4 C Aluminum 655-45947-01 Fitted with shear pin
3 9 6 1/2 C Aluminum 655-45945-00 Fitted with shear pin
3 9 7 C Aluminum 647-45943-00 Fitted with shear pin
3 9 7 1/2 C Aluminum 655-45943-00 Fitted with shear pin
3 9 9 C Aluminum 647-45947-00 Fitted with shear pin
3 9 1/4 9 1/4 C Aluminum 647-45941-00 Fitted with shear pin
Global model 6C 8C F8C F9.9J
US/CA model F8A F9.9B
Blade Dia. (in) Pitch (in) Mark Material Part number Remarks
3 8 1/2 6 1/2 N Aluminum 6G1-45947-00
3 8 1/2 7 1/2 N Aluminum 6G1-45943-00
3 8 1/2 8 N Aluminum 6G1-45952-00
3 8 1/2 8 1/2 N Aluminum 6G1-45941-00
3 8 1/2 9 1/4 N Aluminum 6G1-45954-00
Global model 9.9F 15F E9.9D E15D EK9.9J EK15P EK9.9D EK15D
US/CA model
Global model F9.9H F15C
US/CA model F15A
Blade Dia. (in) Pitch (in) Mark Material Part number Remarks
3 9 1/2 6 1/2 J Aluminum 683-45949-00
3 9 1/4 8 J Aluminum 63V-45947-00
3 9 1/4 9 3/4 J Aluminum 683-45952-00
3 9 1/4 10 J Aluminum 63V-45952-00
3 9 1/4 10 1/2 J Aluminum 683-45943-00
3 9 1/4 11 J Aluminum 63V-45943-00
3 9 1/4 12 J Aluminum 683-45941-00
Global model F9.9H F15C F20B F20C
US/CA model F15A F20A
Blade Dia. (in) Pitch (in) Mark Material Part number Remarks
3 9 1/4 9 J1 Aluminum 63V-45945-10
3 9 1/4 10 J1 Aluminum 63V-45952-10
3 9 1/4 11 J1 Aluminum 63V-45943-10
3 9 1/4 12 J1 Aluminum 63V-45941-10
