3 Connect the Lightning or USB-C 3.5 mm headphone jack adapter to the smartphone
[P] input/output jack of this product with a 3.5 mm 4-conductor (TRRS) stereo mini
cable.
2 2
33
3.5 mm
4-conductor (TRRS)
stereo mini cable
Lightning/USB-C
3.5 mm headphone
jack adapter
Lightning/USB-C
3.5 mm headphone
jack adapter
3.5 mm
4-conductor (TRRS)
stereo mini cable
NOTE
Use a four-conductor stereo mini cable, not a two- or three-conductor cable.
2-conductor (TS) 3-conductor (TRS) 4-conductor (TRRS)
No No Yes
One insulator band Two insulator bands Three insulator bands
44
Using this product in a Web meeting > Using with an iPhone/iPad
