18
USING DIGITAL SOUND FIELD PROCESSOR (DSP)
This unit incorporates a sophisticated, multi-program digital sound field processor, which allows you to expand and shape the audio
sound field from both the audio and video sources, for a theater-like experience in the listening/viewing room.
This digital sound field processor has 8 programs; 6 programs for digital sound field processing and 2 programs for the Dolby Pro
Logic Surround sound system (DOLBY PRO LOGIC and DOLBY PRO LOGIC ENHANCED). You can create an excellent audio
sound field by selecting the suitable program and adding desired adjustments. In addition, when the DOLBY PRO LOGIC or
DOLBY PRO LOGIC ENHANCED program is selected, the built-in automatic input balance control functions. This presents you the
best surround condition without manual adjustment.
Front Panel
Remote Control Transmitter
Displays your selection on the
DSP or other informations.
Switches on/off the digital
sound field processor (DSP)
Selects a digital
sound field program.
Used for speaker balance adjustment
(For details, refer to page 12, 13 and 14.)
Adjusts sound output
level at each speaker.
(For details, refer to
page 20 and 21.)
Adjusts sound output
level at each speaker.
(For details, refer to
page 20 and 21.)
Selects the center channel
output mode. (For details,
refer to page 13.)
Adjusts the delay time.
(For details, refer to
page 21.)
Adjusts the delay time.
(For details, refer to
page 21.)
Selects a digital sound
field program.
Switches on/off the
digital sound field
processor (DSP).
To Next Page
