FEATURES
CONTENTS
3
English
●
5 Speaker Configuration
Front: 70W + 70W (8Ω) RMS Output
Power, 0.04% THD, 20–20,000 Hz
Center: 70W (8Ω) RMS Output Power,
0,07% THD, 20–20,000 Hz
Rear: 20W + 20W (8Ω) RMS Output
Power, 0.3% THD, 1 kHz
●
Digital Sound Field Processor
6 Programs for Digital Sound Field
Processing
2 Programs for Dolby Surround Decoding
(DOLBY PRO LOGIC and DOLBY PRO
LOGIC ENHANCED)
●
Automatic Input Balance Control for
Dolby Surround
●
Test Tone Generator for Easier Speaker
Output Balance Adjustment
●
3 Center Channel Modes
(NORMAL/WIDE/PHANTOM)
●
Video Signal Input/Output Capability
(Including S Video Connections)
●
SLEEP Timer
●
Remote Control Capability
Supplied Accessories ......................................2
Caution ............................................................4
Profile of This Unit ...........................................5
Speaker Setup for This Unit ............................6
Connections ....................................................7
Speaker Balance Adjustment ........................12
Basic Operations ...........................................15
Using Digital Sound Field Processor (DSP) ..18
Setting the SLEEP Timer ..............................22
Remote Control Transmitter ..........................23
Notes about the Remote Control Transmitter
.......................................................................24
Troubleshooting .............................................25
Specifications ................................................26
Thank you for selecting this YAMAHA digital sound field processing amplifier.
