Yamaha DSP-AX2 Service Manual

DSP-AX2
DSP-AX2
22
THM PRD PRV
028 006 009
The above figures are ex-
amples for reference.
THM/PRD/PRV [Remote control code: 7A—0B (CD SKIP –)]
(Detection of the temperature of the heat sink and protection function)
THM: Detection of the temperature of the heat sink
(Normal value: 6~40) 0.3V~ 2.0V (reference voltage)
At 5% or less, the protection function works to turn off the power. At more than 40%,
possibility is that there is an error in the temperature detection system.
PRD: Protection value for DC detection (Normal value: 1~13) 0.05V~ 0.65V (reference voltage)
When the value is out of the normal value range, the protection function works to turn
off the power.
PRV: Protection value for power voltage (Normal value: 5~15) 0.25V~ 0.75V (reference voltage)
When the value is out of the normal value range, the protection function works to turn
off the power.
KY0 KY1 RECOUT
100 100 060
KY0/KY1/RECOUT (Detection of key scan/REC OUT)[Remote control code: ––––]
(*1) : “EFFECT” and “6CH INPUT” keys pressed
simultaneously
Indicate KY0
0 INPUT w
10 INPUT q
20 INPUT MODE
30 DIAG(*1)
40 6CH INPUT
50 EFFECT
60 SPEAKERS A
70 SPEAKERS B
80 PROC. DIRECT
90 BASS EXTENS.
100 KEY OFF state
Indicate KY1
0 –
10 –
20 –
30 –
40 –
50 –
60 –
70 –
80 –
90 –
100 KEY OFF state
Indicate REC OUT
0 MD/TAPE
15 SAT
30 CD
44 V-AUX
60 SOURCE
76 CABLE
92 PHONO
122 CD-R
137 VCR 1
153 TUNER
170 VCR 2/DVR
186 DVD
202 D-TV/LD
KY0/KY1: Panel key of the main unit (10% step)
• When the standard value is deviated by ±4%, KEY A/D fails to function properly. In this
case, check the circuit voltages, soldering condition, etc.
RECOUT: Indicates selected REC OUT position
(AD conversion value 100%: 255)
