Yamaha DSP-AX2 Service Manual

DSP-AX2
DSP-AX2
5
● SET MENU TABLE
No. SET MENU PRESET VALUE SETTING RANGES
1. SPEAKER SET
1A CENTER SPEAKER LARGE LARGE/SMALL/NONE
1B MAIN SPEAKER LARGE LARGE/SMALL
1C REAR L/R SPEAKER LARGE LARGE/SMALL/NONE
1D REAR CT SPEAKER LARGE LARGE/SMALL/NONE
1E LFE/BASS OUT BOTH SUBWOOFER/MAIN/BOTH
1F FRONT EFFECT SPEAKER YES YES/NONE
1G MAIN LEVEL NORMAL NORMAL/–10dB
2. LOW FREQ. TEST TONE : OFF ON/OFF
OUTPUT : MAIN L/R L/C/R/RS/RC/LS/SW/FRONT
FREQUENCY : 88Hz 35 — 250Hz
3. L/R BALANCE 0 L — 0 — R (0.5 step) (L/R 10.0)
4. HP TONE CTRL BASS : 0dB –6dB — +3dB
TREBLE : 0dB –6dB — +3dB
5. CENTER GRAPHIC EQ. EACH ch : 0dB 100Hz — 10kHz, –6dB — +6dB
6. INPUT RENAME DVD(Currently selected input)
7. I/O ASSIGNING
7A COMPONENT VIDEO INPUT [A] : DVD DVD, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, V-AUX
[B] : D-TV/LD DVD, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, V-AUX
7B OPTICAL OUT (1) : MD/TAPE DVD, MD/TAPE, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, V-AUX, PHONO, CD, TUNER, CD-R
(2) : CD-R DVD, MD/TAPE, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, V-AUX, PHONO, CD, TUNER, CD-R
7C OPTICAL IN (3) : CD CD, TUNER, CD-R, MD/TAPE, DVD, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, PHONO
(4) : CD-R CD, TUNER, CD-R, MD/TAPE, DVD, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, PHONO
(5) : DVD CD, TUNER, CD-R, MD/TAPE, DVD, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, PHONO
(6) : D-TV/LD CD, TUNER, CD-R, MD/TAPE, DVD, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, PHONO
(7) : SAT CD, TUNER, CD-R, MD/TAPE, DVD, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, PHONO
7D COAXIAL IN (8) : CD CD, TUNER, CD-R, MD/TAPE, DVD, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, V-AUX, PHONO
(9) : CABLE CD, TUNER, CD-R, MD/TAPE, DVD, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, V-AUX, PHONO
(10) : LD RF (R, T only) LD RF, CD, TUNER, CD-R, MD/TAPE, DVD, D-TV/LD, CABLE, SAT, VCR1, VCR2/DVR, V-AUX, PHONO
8. INPUT MODE DVD : AUTO AUTO/LAST
9. PARAMETER INITIALIZE OFF PROGRAM 1 — 12
10. DOLBY DIGITAL SET
10A LFE LEVEL SPEAKER : 0dB –20dB — 0dB
HEAD PHONE : 0dB –20dB — 0dB
10B DYNAMIC RANGE SPEAKER : MAX MAX/STD/MIN
HEAD PHONE : MAX MAX/STD/MIN
11. DTS SET
11A LFE LEVEL SPEAKER : 0dB –10dB — +10dB
HEAD PHONE : 0dB –10dB — +10dB
12. 6.1/ES AUTO ON ON/OFF
13. SPEAKER DELAY TIME CENTER : 0ms 0ms — 5ms (1ms step)
REAR CENTER : 3ms 0ms — 30ms
14. DISPLAY SET BLUE BACK : AUTO AUTO/OFF
OSD SHIFT : 0 –5 — +5
DIMMER : 0 –4 — 0
15. MEMORY GUARD OFF ON/OFF
S : S video signal
V : Composite video signal
O : YES
X: NO
— : NO CARE
Caution: Superimposing function is not usable for component signals.
● SUPERIMPOSING
Input LD, etc. Output Superimposing
Terminal Signal Monitor connection
S O O O (On screen)
VO — X
SO X X
VO — O (On screen)
S O O O (On screen)
VX — X
SO X X
VX — O (Blue back)
SX — X
VO — X (On screen)
SX — O (Blue back)
VX — O (Blue back)
