■ AUDIO SECTION
Minimum RMS Output Power per Channel
MAIN, 20Hz to 20kHz, 0.02% THD, 8Ω . . . 100W+100W
CENTER, 20Hz to 20kHz, 0.02% THD, 8Ω . . . . . . 100W
REAR, 20Hz to 20kHz, 0.02% THD, 8Ω . . . 100W+100W
REAR CENTER,
20Hz to 20kHz, 0.02% THD, 8Ω . . . . . . . . . . . . . . . 100W
FRONT, 1kHz, 0.05% THD, 8Ω . . . . . . . . . . . . 25W+25W
Maximum Power per Channel (R, T models only)
MAIN, 1kHz, EIAJ, 10% THD, 8Ω . . . . . . . . 140W+140W
CENTER, 1kHz, EIAJ, 10% THD, 8Ω . . . . . . . . . . . 140W
REAR, 1kHz, EIAJ, 10% THD, 8Ω . . . . . . . 140W+140W
REAR CENTER, 1kHz, EIAJ, 10% THD, 8Ω . . . . . 140W
FRONT, 1kHz, EIAJ, 10% THD, 8Ω . . . . . . . . 35W+35W
Dynamic Power per Channel (R, T models only)
MAIN, 8/6/4/2Ω . . . . . . . . . . . . . . . . . . 140/170/220/320W
Dynamic Headroom (R, T models only)
8Ω . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.46dB
DIN Standard Output Power per Channel (B, G models only)
MAIN, 1kHz, 0.7% THD, 4Ω . . . . . . . . . . . . 160W+160W
CENTER, 1kHz, 0.7% THD, 4Ω . . . . . . . . . . . . . . . 160W
REAR, 1kHz, 0.7% THD, 4Ω . . . . . . . . . . . . 160W+160W
REAR CENTER, 1kHz, 0.7% THD, 4Ω . . . . . . . . . . 160W
FRONT, 1kHz, 0.7% THD, 4Ω . . . . . . . . . . . . . 40W+40W
IEC Power (B, G models only)
MAIN, 1kHz, 0.015% THD, 8Ω . . . . . . . . . . . . . . . . 115W
Power Band Width
MAIN, 0.08% THD, 50W/8Ω . . . . . . . . . . . 10Hz to 50kHz
Damping Factor
MAIN, 20Hz to 20kHz, 8Ω . . . . . . . . . . . . . . . 200 or more
Input Sensitivity/Impedance
CD, etc (1kHz, 100W/8Ω) . . . . . . . . . . . . . . 150mV/47kΩ
PHONO MM . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5mV/47kΩ
MAIN IN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1V/47kΩ
Maximum Input Signal Level
PHONO MM, 1kHz, 0.05% THD, (Effect on) . . . . 110mV
CD, etc, (Effect on) . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3V
Output Level/Impedance
REC OUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150mV/1kΩ
PRE OUT (MAIN, etc) . . . . . . . . . . . . . . . . . . . . 1V/1.2kΩ
SUB WOOFER (EFFECT OFF, MAIN SP : SMALL)
MONO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.0V/1.2kΩ
Maximum Voltage Output (20Hz to 20kHz, 1% THD)
PRE OUT (MAIN L/R) . . . . . . . . . . . . . . . . . . . . . . . . 1.5V
Headphone Jack Rated Output/Impedance
CD, etc (1kHz, 40mV, 8Ω) . . . . . . . . . . . . . . 150mV/100Ω
Frequency Response
CD, etc (10Hz to 100kHz, MAIN L/R) . . . . . . . . +0/-3.0dB
MAIN IN (5Hz to 100kHz, MAIN L/R) . . . . . . . . +0/-3.0dB
RIAA Equalization Deviation (20Hz to 20kHz)
PHONO MM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0±0.5dB
Tone Control Characteristics
BASS : Boost/cut . . . . . . . . . . . . . . . . . . ±10dB (50Hz)
Turnover Frequency . . . . . . . . . . . . . . . . 350Hz
TREBLE : Boost/cut . . . . . . . . . . . . . . . . . .±10dB (20kHz)
Turnover Frequency . . . . . . . . . . . . . . . 3.5kHz
Center Graphic Equalizer
Frequency . . . . . . . . . . . . 100/300/1k/3k/10kHz
Boost/cut . . . . . . . . . . . . . . . . . . . . . . . . . .±6dB
Q . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.7
Bass Extension . . . . . . . . . . . . . . . . . . . . . . . . . .+6dB (60Hz)
Filter Characteristics
MAIN, CENTER, REAR SP SMALL
: H.P.F. . . . . . . . . . . . . . . fc = 90Hz, 12dB/oct.
SUB WOOFER OUT : L.P.F. . . . . . . fc = 90Hz, 18dB/oct.
■ SPECIFICATIONS
■ VIDEO SECTION
Video Signal Type
B, G models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .PAL
R, T models . . . . . . . . . . . . . . . . . . . . . . . . . . . NTSC/PAL
Composite Video Signal Level . . . . . . . . . . . . . . 1Vp-p/75Ω
S-Video Signal Level
Y . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1Vp-p/75Ω
C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.286Vp-p/75Ω
Component Signal Level
Y . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1Vp-p/75Ω
Cb/Cr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.7Vp-p/75Ω
Video Maximum Input Level . . . . . . . . . . . . . . . . . .1.5Vp-p
Video Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . . 50dB
Monitor Output Frequency Response
Composite Video Signal . . . . . . . . . . . 5Hz~10MHz, –3dB
S-Video Signal . . . . . . . . . . . . . . . . . . 5Hz~10MHz, –3dB
Component Signal . . . . . . . . . . . . . . . . DC~30MHz, –3dB
Total Harmonic Distortion (20Hz to 20kHz)
PHONO MM to REC OUT (3V) . . . . . . . . . . . . . . . . 0.01%
CD, etc, to PRE OUT MAIN L/R (1V) . . . . . . . . . . 0.005%
CD, etc, to SP OUT L/R (50W/8Ω) . . . . . . . . . . . . 0.015%
MAIN IN to SP OUT (50W/8Ω) . . . . . . . . . . . . . . . 0.008%
Signal-to-Noise Ratio (IHF-A-Network)
PHONO MM, Input Shorted 5mV (Effect off) . . . . . . 86dB
CD, etc, Input Shorted 150mV (Effect off) . . . . . . . . 96dB
CD, etc, Input Shorted 250mV (Effect off) . . . . . . . 100dB
Residual Noise (IHF-A-Network)
MAIN, SP OUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150µV
Channel Separation (Vol. –30dB, Effect off)
PHONO MM, Input Shorted, 1kHz/10kHz . . . . 60dB/55dB
CD, etc, Input 5.1kΩ Shorted, 1kHz/10kHz . . 60dB/45dB
Muting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . – ∞
