Yamaha DSP-AX2 Service Manual

DSP-AX2
DSP-AX2
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
83
P.C.B. DSP & F AMP
IC527 XF291A00 IC uPC4570G2
L51 V2726500 COIL 68uH
L52 V2726500 COIL 68uH
L53 V2726500 COIL 68uH
L54 V2726500 COIL 68uH
L55 V2726500 COIL 68uH
L56 VT623200 FLTR.LC SBP‑4930(RT)
L57 V2726500 COIL 68uH(RT)
PJ501 V5715300 JACK.PIN 2P(BG)
* PJ501 V6290500 JACK.PIN 3P(RT)
Q51 iA103700 TR.CHP 2SA1037Q,R,S(RT)
Q52 VV556400 TR 2 SC2412KQ,R,S(RT)
Q53 VV556400 TR 2SC2412K Q,R,S(RT)
Q54 VV556400 TR 2SC2412K Q,R,S(RT)
Q55 iA103700 TR.CHP 2SA1037Q,R,S(RT)
Q56 VV556400 TR 2SC2412K Q,R,S(RT)
Q57 VV556400 TR 2SC2412K Q,R,S(RT)
Q58 iA103700 TR.CHP 2SA1037Q,R,S(RT)
Q59 VV655300 TR.DGT DTA144EKA
Q510 VV655300 TR.DGT DTA144EKA
Q511 VV655300 TR.DGT DTA144EKA
Q512 VV655300 TR.DGT DTA144EKA
Q513 VV655300 TR.DGT DTA144EKA
Q514 VV655300 TR.DGT DTA144EKA
Q515 VV655300 TR.DGT DTA144EKA
Q516 VV655300 TR.DGT DTA144EKA
Q517 VV655300 TR.DGT DTA144EKA
Q518 VV655300 TR.DGT DTA144EKA
Q519 VD303700 TR 2SC3326A,B
Q520 VD303700 TR 2SC3326A,B
Q521 VD303700 TR 2SC3326A,B
Q522 VD303700 TR 2SC3326A,B
Q523 VD303700 TR 2SC3326A,B
Q524 VD303700 TR 2SC3326A,B
Q525 VD303700 TR 2SC3326A,B
Q526 VD303700 TR 2SC3326A,B
Q527 VD303700 TR 2SC3326A,B
R594 HV453100 R.CAR.FP 1Ω1/4W(RT)
R595 HV453100 R.CAR.FP 1Ω1/4W(RT)
R596 HV454100 R.CAR.FP 10Ω1/4W
R599 HV453100 R.CAR.FP 1Ω1/4W
R6 HV453100 R.CAR.FP 1Ω1/4W
R61 HV454220 R.CAR.FP 22Ω1/4W
R62 HV453220 R.CAR.FP 2.2Ω1/4W
R64 HV454220 R.CAR.FP 22Ω1/4W
R65 HV453220 R.CAR.FP 2.2Ω1/4W
R66 HV454100 R.CAR.FP 10Ω1/4W
R68 HV454220 R.CAR.FP 22Ω1/4W
R69 VU224000 R.MTL.FLM 0.22Ω1WJ
R610 HV453220 R.CAR.FP 2.2Ω1/4W
R611 HV453220 R.CAR.FP 2.2Ω1/4W
R612 HV453220 R.CAR.FP 2.2Ω1/4W
XL501 V3625700 RSNR.CRYS 24.576MHz
XL502 VT928600 RSNR.CRYS 18.432MHz(RT)
* V6602700 P.C.B. FAMP(RT)
* V6602800 P.C.B. FAMP(B)
* V6602900 P.C.B. FAMP(G)
CB311 VG879900 CN.BS.PIN 2P(RTB)
CB313 VP206500 HOLDER.FUS EYF‑52BCT(BG)
CB313 VS996100 HOLDER.FUS EYF64BC(RT)
CB314 VS996100 HOLDER.FUS EYF64BC(RT)
CB315 VP206500 HOLDER.FUS EYF‑52BCT(BG)
CB316 LA002410 TERM.WRAP 2P
CB317 VP206500 HOLDER.FUS EYF‑52BCT(RTG)
CB318 VP206500 HOLDER.FUS EYF‑52BCT(RTG)
CB319 LA002410 TERM.WRAP 2P(RT)
CB351 VD004500 CN.BS.PIN 2P
CB352 VL845000 CN.BS.PIN 6P
CB353 VP206500 HOLDER.FUS EYF‑52BCT
CB354 VP206500 HOLDER.FUS EYF‑52BCT
CB355 VP206500 HOLDER.FUS EYF‑52BCT
CB356 VP206500 HOLDER.FUS EYF‑52BCT
CB357 VD004500 CN.BS.PIN 2P
* CB358 LA002320 TERM.WRAP 3P
* CB359 LA002320 TERM.WRAP 3P
* CB360 LA002000 TERM.WRAP 2P
* CB361 VD005000 CN.BS.PIN 7P
* CB362 VD004700 CN.BS.PIN 4P
* CB363 VD005000 CN.BS.PIN 7P
C311 UU147100 C.EL 10uF25V(BG)
* C311 UU148100 C.EL 100uF25V(RT)
C312 UU147100 C.EL 10uF25V(RT)
C313 UU167100 C.EL 10uF50V(RT)
C314 UU197470 C.EL 47uF100V(RT)
C315 Vi716700 C.MYLAR 0.01uF50V(BG)
C316 Vi716700 C.MYLAR 0.01uF50V(RT)
C317 Vi716700 C.MYLAR 0.01uF50V(RT)
Z * C318 V6185300 C.CE.SAFTY 0.01uF275V
C351 UU167100 C.EL 10uF50V
C352 UU167100 C.EL 10uF50V
* C353 UU157330 C.EL 33uF35V
* C354 UU157330 C.EL 33uF35V
C355 UU167100 C.EL 10uF50V
C356 UU167100 C.EL 10uF50V
C357 VF467000 C.CE.TUBLR 1000pF50V
C358 UU137220 C.EL 22uF16V
C359 VF466800 C.CE.TUBLR 100pF50V
C360 VS696700 C.CE 33pF500V
C361 UP652100 C.POL 100pF100V
* C362 UU148100 C.EL 100uF25V
C363 UU137470 C.EL 47uF16V
C364 UU137220 C.EL 22uF16V
C365 VF466800 C.CE.TUBLR 100pF50V
