Yamaha DSP-AX2 Service Manual

95 96
DSP-AX2
P.C.B. OPERATION
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
CHIP RESISTOR
RD350000 R.CAR.CHP 0Ω1/10W
RD353100 R.CAR.CHP 1Ω1/10W
RD353220 R.CAR.CHP 2.2Ω1/10W
RD354330 R.CAR.CHP 33Ω1/10W
RD354470 R.CAR.CHP 47Ω1/16W
RD354680 R.CAR.CHP 68Ω1/16W
RD354750 R.CAR.CHP 75Ω1/10W
RD355100 R.CAR.CHP 100Ω1/10W
RD355150 R.CAR.CHP 150Ω1/10W
RD355220 R.CAR.CHP 220Ω1/10W
RD355330 R.CAR.CHP 330Ω1/10W
RD355470 R.CAR.CHP 470Ω1/10W
RD355510 R.CAR.CHP 510Ω1/16W
RD355820 R.CAR.CHP 820Ω1/10W
RD356100 R.CAR.CHP 1KΩ1/10W
RD356120 R.CAR.CHP 1.2KΩ1/10W
RD356150 R.CAR.CHP 1.5KΩ1/10W
RD356180 R.CAR.CHP 1.8KΩ1/10W
RD356220 R.CAR.CHP 2.2KΩ1/10W
RD356270 R.CAR.CHP 2.7KΩ1/10W
RD356330 R.CAR.CHP 3.3KΩ1/10W
RD356430 R.CAR.CHP 4.3KΩ1/10W
RD356470 R.CAR.CHP 4.7KΩ1/10W
RD356560 R.CAR.CHP 5.6KΩ1/10W
RD356680 R.CAR.CHP 6.8KΩ1/10W
RD356820 R.CAR.CHP 8.2KΩ1/10W
RD357100 R.CAR.CHP 10KΩ1/10W
RD357150 R.CAR.CHP 15KΩ1/10W
RD357180 R.CAR.CHP 18KΩ1/10W
RD357220 R.CAR.CHP 22KΩ1/10W
RD357270 R.CAR.CHP 27KΩ1/10W
RD357470 R.CAR.CHP 47KΩ1/10W
RD357560 R.CAR.CHP 56KΩ1/10W
RD357820 R.CAR.CHP 82KΩ1/10W
RD358100 R.CAR.CHP 100KΩ1/10W
RD358120 R.CAR.CHP 120KΩ1/10W
RD358220 R.CAR.CHP 220KΩ1/10W
RD358330 R.CAR.CHP 330KΩ1/16W
RD358470 R.CAR.CHP 470KΩ1/10W
RD358680 R.CAR.CHP 680KΩ1/10W
RD359100 R.CAR.CHP 1MΩ1/10W
RD359220 R.CAR.CHP 2.2MΩ1/10W
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
C835 UU139100 C.EL 1000uF16V
C836 UU139100 C.EL 1000uF16V
* C837 VR168400 C.MYLAR.ML ECQ‑V1H124JL3
* C838 VR168400 C.MYLAR.ML ECQ‑V1H124JL3
C891 VF467000 C.CE.TUBLR 1000pF50V
C892 VF467000 C.CE.TUBLR 1000pF50V
C893 VF467000 C.CE.TUBLR 1000pF50V
C894 VJ599100 C.CE.TUBLR 0.1uF50V
C901 VJ599100 C.CE.TUBLR 0.1uF50V
C902 VJ599100 C.CE.TUBLR 0.1uF50V
C903 VJ599100 C.CE.TUBLR 0.1uF50V
C904 VJ599100 C.CE.TUBLR 0.1uF50V
C905 VJ599100 C.CE.TUBLR 0.1uF50V
C906 VJ599100 C.CE.TUBLR 0.1uF50V
C907 VJ599100 C.CE.TUBLR 0.1uF50V
C908 US135100 C.CE.CHP 0.1uF16V
C909 UU137100 C.EL 10uF16V
C910 US135100 C.CE.CHP 0.1uF16V
C911 VJ599100 C.CE.TUBLR 0.1uF50V
C912 VJ599100 C.CE.TUBLR 0.1uF50V
C913 VJ599100 C.CE.TUBLR 0.1uF50V
C914 VJ599100 C.CE.TUBLR 0.1uF50V
C915 US135100 C.CE.CHP 0.1uF16V
C916 VJ599100 C.CE.TUBLR 0.1uF50V
C917 VJ599100 C.CE.TUBLR 0.1uF50V
C918 VJ599100 C.CE.TUBLR 0.1uF50V
C919 UU167100 C.EL 10uF50V
C920 VJ599100 C.CE.TUBLR 0.1uF50V
* C921 UU118330 C.EL 330uF6.3V
C922 US135100 C.CE.CHP 0.1uF16V
C923 US062100 C.CE.M.CHP 100pF50V
C924 US135100 C.CE.CHP 0.1uF16V
C925 VJ599100 C.CE.TUBLR 0.1uF50V
C926 VJ599100 C.CE.TUBLR 0.1uF50V
C927 US060700 C.CE.CHP 7pF50V
C935 US135100 C.CE.CHP 0.1uF16V
C937 US135100 C.CE.CHP 0.1uF16V
C938 US062100 C.CE.M.CHP 100pF50V
C939 US062100 C.CE.M.CHP 100pF50V
C940 US135100 C.CE.CHP 0.1uF16V
C941 US135100 C.CE.CHP 0.1uF16V
D801 VG439100 DIODE.ZENR MTZJ9.1A9.1V
D802 VG439100 DIODE.ZENR MTZJ9.1A9.1V
D803 VU264100 DIODE 1SR139‑400
D804 VU264100 DIODE 1SR139‑400
* D901 VG438300 DIODE.ZENR MTZJ6.8B6.8V
IC801 iG001270 IC TC4066BP
IC802 XM356A00 IC NJM2068LD
IC803 XB247A00 IC uPC4570HA
IC804 XP844A00 IC NJM4556AL
* IC901 XY115A00 IC M66004MAFP‑200C
* IC902 XY115A00 IC M66004MAFP‑200C
* JK831 V4164400 JACK.PHONE YKB21‑5209
JK935 V2589500 CN 1P
L935 V2726500 COIL 68uH
PJ935 VS868400 JACK.PIN 3P
Q801 VG721700 TR.DGT DTA144ES
Q802 VG722000 TR.DGT DTC144ES
Q803 VK432900 TR 2SD1915FS,T
Q804 VK432900 TR 2SD1915FS,T
Q901 VV556400 TR 2SC2412KQ,R,S
Q902 VV556400 TR 2SC2412KQ,R,S
Q903 VV556400 TR 2SC2412KQ,R,S
Q904 VV556400 TR 2SC2412KQ,R,S
Q905 VV556400 TR 2SC2412KQ,R,S
Q906 VV556400 TR 2SC2412KQ,R,S
Q907 VV556400 TR 2SC2412KQ,R,S
Q908 VV556400 TR 2SC2412KQ,R,S
Q909 VV556400 TR 2SC2412KQ,R,S
Q910 VV556400 TR 2SC2412KQ,R,S
Q911 VV556400 TR 2SC2412KQ,R,S
Q935 VV556400 TR 2SC2412KQ,R,S
Q936 VV556500 TR 2SA1037KQ,R,S
R803 HV753330 R.CAR.FP 3.3Ω1/4W
R804 HV753330 R.CAR.FP 3.3Ω1/4W
R839 HV755100 R.CAR.FP 100Ω1/4W
R840 HV755100 R.CAR.FP 100Ω1/4W
R841 HV755220 R.CAR.FP 220Ω1/4W
R842 HV755220 R.CAR.FP 220Ω1/4W
* R846 VP439800 R.MTL.FLM 2.2KΩ1/4WF
* R847 VP439800 R.MTL.FLM 2.2KΩ1/4WF
* R848 VP439800 R.MTL.FLM 2.2KΩ1/4WF
* R849 VP439800 R.MTL.FLM 2.2KΩ1/4WF
R850 VP441600 R.MTL.FLM 12KΩ 1/4W
R851 VP441600 R.MTL.FLM 12KΩ 1/4W
R852 VP441600 R.MTL.FLM 12KΩ 1/4W
* R853 VP442300 R.MTL.FLM 24KΩ1/4WF
* R854 VP442300 R.MTL.FLM 24KΩ1/4WF
* R855 VP442300 R.MTL.FLM 24KΩ1/4WF
* R856 VP442300 R.MTL.FLM 24KΩ1/4WF
* R857 VP442300 R.MTL.FLM 24KΩ1/4WF
ST891 BB071360 SCR.TERM 8.3x13
* ST901 VP750600 SCR.TERM MEP1700
ST935 BB071360 SCR.TERM 8.3x13
* SW801 V6217400 SW.RT.ENC REB161PHD20FHINA1
* SW802 V6154100 SW.RT.ENC SDB161PH20FS‑1‑13
* SW901 V4757100 SW.TACT EVQ11A
* SW902 V4757100 SW.TACT EVQ11A
* SW903 V4757100 SW.TACT EVQ11A
* SW972 V4757100 SW.TACT EVQ11A
* SW977 V4757100 SW.TACT EVQ11A
* SW985 V6886700 SW.RT.ENC
* SW990 V4757100 SW.TACT EVQ11A
* SW991 V4757100 SW.TACT EVQ11A
* SW992 V4757100 SW.TACT EVQ11A
* SW993 V4757100 SW.TACT EVQ11A
* SW994 V4757100 SW.TACT EVQ11A
U901 VZ411100 L.DTCT GP1U281X
* V901 V6291200 FL.DSPLY 32‑BT‑07G
VR801 VP741800 VR B20KΩ
VR802 VP741900 VR G25KΩ
* V6006800 SHEET
* VZ628400 SUPRT
