■ SPECIFICATIONS / 参考仕様
■ Audio Section/オーディオ部
Minimum RMS Output Power (Power Amp. Section)/定格出力(パ
ワーアンプ部)
[RX-V557]
(20 Hz to 20 kHz, 0.09% THD, 8 ohms)
FRONT L/R ................................................................. 90 W + 90 W
CENTER ................................................................................. 90 W
SURROUND L/R ........................................................ 90 W + 90 W
SURROUND BACK ................................................................ 90 W
[HTR-5850]
(1 kHz, 0.7% THD, 8 ohms)
FRONT L/R ............................................................ 105 W + 105 W
CENTER ............................................................................... 105 W
SURROUND L/R ................................................... 105 W + 105 W
SURROUND BACK .............................................................. 105 W
[DSP-AX557] (J model)
(20 Hz to 20 kHz, 0.09% THD, 6 ohms)
FRONT L/R ................................................................. 90 W + 90 W
CENTER ................................................................................. 90 W
SURROUND L/R ........................................................ 90 W + 90 W
SURROUND BACK ................................................................ 90 W
[RX-V457]
(20 Hz to 20 kHz, 0.09% THD, 8 ohms)
FRONT L/R ................................................................. 85 W + 85 W
CENTER ................................................................................. 85 W
SURROUND L/R ........................................................ 85 W + 85 W
SURROUND BACK ................................................................ 85 W
[HTR-5840]
(1 kHz, 0.7% THD, 8 ohms)
FRONT L/R ............................................................ 100 W + 100 W
CENTER ............................................................................... 100 W
SURROUND L/R ................................................... 100 W + 100 W
SURROUND BACK .............................................................. 100 W
[DSP-AX457] (J model)
(20 Hz to 20 kHz, 0.09% THD, 6 ohms)
FRONT L/R ................................................................. 85 W + 85 W
CENTER, REAR CENTER ..................................................... 85 W
SURROUND L/R ........................................................ 85 W + 85 W
SURROUND BACK ................................................................ 85 W
Maximum Power/実用最大出力 (EIAJ) (1 kHz, 10% THD)
[RX-V557/HTR-5850] (R, T, K, L models)
FRONT L/R (8 ohms) ............................................ 130 W + 130 W
CENTER, REAR CENTER (8 ohms) ................................... 130 W
SURROUND L/R (8 ohms) .....................................130 W + 130 W
SURROUND BACK (8 ohms) .............................................. 130 W
[DSP-AX557] (J model)
FRONT L/R (6 ohms) ............................................ 130 W + 130 W
CENTER, REAR CENTER (6 ohms) ................................... 130 W
SURROUND L/R (6 ohms) .....................................130 W + 130 W
SURROUND BACK (6 ohms) .............................................. 130 W
[RX-V457/HTR-5840] (R, T, K, L models)
FRONT L/R (8 ohms) ............................................ 125 W + 125 W
CENTER, REAR CENTER (8 ohms) ................................... 125 W
SURROUND L/R (8 ohms) .....................................125 W + 125 W
SURROUND BACK (8 ohms) .............................................. 125 W
[DSP-AX457] (J model)
FRONT L/R (6 ohms) ............................................ 125 W + 125 W
CENTER, REAR CENTER (6 ohms) ................................... 125 W
SURROUND L/R (6 ohms) .....................................125 W + 125 W
SURROUND BACK (6 ohms) .............................................. 125 W
DIN Standard Output Power Per Channel/DINパワー (1 kHz, 0.7%
THD, 4 ohms)
[RX-V557/HTR-5850] (B, G, E models)
FRONT L/R ............................................................ 135 W + 135 W
CENTER ............................................................................... 135 W
SURROUND L/R ................................................... 135 W + 135 W
SURROUND BACK .............................................................. 135 W
[RX-V457/HTR-5840] (B, G, E models)
FRONT L/R ............................................................ 130 W + 130 W
CENTER ............................................................................... 130 W
SURROUND L/R ................................................... 130 W + 130 W
SURROUND BACK .............................................................. 130 W
IEC Power / IECパワー (1 kHz, 0.06% THD, 8 ohms)
[RX-V557/HTR-5850] (B, G, E, L models)
FRONT L/R ............................................................ 100 W + 100 W
[RX-V457/HTR-5840] (B, G, E, L models)
FRONT L/R ................................................................. 95 W + 95 W
Dynamic Power Per Channel/ダイナミックパワー (IHF) (8/6/4/2
ohms)
[RX-V557/HTR-5850]
FRONT L/R ...................................................... 120/155/190/235 W
[DSP-AX557] (J model)
FRONT L/R .......................................................... –/130/160/205 W
[RX-V457/HTR-5840]
FRONT L/R ...................................................... 115/150/185/230 W
[DSP-AX457] (J model)
FRONT L/R .......................................................... –/125/155/200 W
Dynamic Headroom/ダイナミックヘッドルーム (8 ohms)
[RX-V557/HTR-5850] (U, C models) .................................... 1.25 dB
[RX-V457/HTR-5840] (U, C models) .................................... 1.31 dB
Damping Factor/ダンピングファクタ
20 Hz to 20 kHz, SPEAKER-A .................................... 120 or more
Input Sensitivity / Input Impedance(入力感度/入力インピーダンス)
CD, etc. ........................................................... 200 mV / 47 k-ohms
MULTI CH IN
FRONT L/R, CENTER, SURROUND L/R, SUB WOOFER
.................................................................. 200 mV / 47 k-ohms
Maximum Input Signal Level /最大許容入力 (1 kHz, 0.5% THD)
CD, etc. (Effect On) .................................................. 2.2 V or more
Output Level / Output Impedance(出力電圧/出力インピーダンス)
REC OUT ....................................................... 200 mV / 1.2 k-ohms
20 Hz SUB WOOFER .......................................... 4 V / 1.2 k-ohms
[RX-V557] (U, C, A, B, G, E models)
ZONE2 OUT .................................................. 200 mV / 1.2 k-ohms
Headphone Jack Rated Output / Impedance (ヘッドフォン出力/出
力インピーダンス)
CD, etc. (1 kHz, 50 mV, 8 ohms) .................... 150 mV / 100 ohms
Frequency Response/周波数特性
CD, etc. to FRONT L/R (10 Hz to 100 kHz) .................. +0/-3.0 dB
Total Harmonic Distortion/全高調波歪率
(20 Hz to 20 kHz, 40 W, 8 ohms)
CD, etc. (Effect Off) to FRONT L/R SP OUT ........... 0.06 % or less
Signal to Noise Ratio / 信号対雑音比 (IHF-A Network)
CD, etc. (Input shorted) SP OUT
250 mV ................................................................. 100 dB or more
Residual Noise/残留ノイズ (IHF-A Network)
FRONT L/R SP OUT ............................................... 150 µV or less
Channel Separation/チャンネルセパレーション
CD, etc. (Input 5.1 k-ohms shorted, 1 kHz/10 kHz)
60 dB or more/45 dB or more
Tone Control Characteristics/トーンコントロール特性
BASS
Boost/Cut ............................................................. ±10 dB (60 Hz)
TREBLE
Boost/Cut ........................................................... ±10 dB (20 kHz)
Filter Characteristics/フィルター特性
FRONT L/R, CENTER, SURROUND L/R, SURROUND BACK SP
Small (H.P.F.)
fc= 40/60/80/90/100/110/120/160/200 Hz / 12 dB/ oct.
SUBWOOFER (L.P.F.)
fc= 40/60/80/90/100/110/120/160/200 Hz / 24 dB/ oct.
■ Video Section/ビデオ部
Video Signal Type/ビデオ信号方式
U, C, R, K, J models .............................................................. NTSC
T, A, B, G, E, L models ............................................................ PAL
Video Signal Type (Video Conversion)/ビデオ信号方式（ビデオ
コンバージョン）
[RX-V557/HTR-5850/DSP-AX557]
U, C, R, K, A, B, G, E, L, J models ....................................... NTSC
R, T, A, B, G, E, L models ........................................................ PAL
Composite Video Signal Level/コンポジットビデオ信号
1 Vp-p / 75 ohms
S-Video Signal Level/Sビデオ信号
Y ........................................................................... 1 Vp-p / 75 ohms
C ................................................................... 0.286 Vp-p / 75 ohms
Component Signal Level (U, C, R, T, K, A, B, G, E, L models)
Y ........................................................................... 1 Vp-p / 75 ohms
Cb/Cr ................................................................ 0.7 Vp-p / 75 ohms
