Yamaha DSP-AX540 User Manual

RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540
RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440
15
RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540
RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440
Monitor Out Frequency Response/モニターアウト周波数帯域
[RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540]
Video Signal Level, S-Video Signal Level ... 5 Hz to 10 MHz, -3 dB
Component Video Signal Level [U, C, A, B, G, L, R, T, K models]
...................................................................... DC to 30 MHz, -3 dB
D4-Video Signal Level [J model] ................ DC to 60 MHz, -3 dB
[RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440]
Video Signal Level ..................................... 5 Hz to 10 MHz, -3 dB
Component Video Signal Level [U, C, A, B, G, L, R, T, K models]
.................................................................... 5 Hz to 30 MHz, -3 dB
D4-Video Signal Level [J model] ................ DC to 60 MHz, -3 dB
■ FM Section/FM部
Tuning Range
U, C models ..................................................... 87.5 to 107.9 MHz
A, B, G, L, K models ........................................ 87.5 to 108.0 MHz
R, T models ......................... 87.5 to 108.0 / 87.50 to 108.00 MHz
J model ............................................................... 76.0 to 90.0 MHz
50dB Quieting Sensitivity/50dBSN感度 (IHF)
(1kHz, 100% Mod.)
Mono .................................................................. 2.0 µV (17.3 dBf)
Stereo .................................................................. 25 µV (39.2 dBf)
Usable Sensitivity/実用感度 (IHF)
Mono .................................................................. 1.0 µV (11.2 dBf)
Selectivity/選択度
at 400 kHz ............................................................................ 70 dB
Signal to Noise Ratio/信号対雑音比 (IHF)
Mono / Stereo .......................................................... 76 dB / 70 dB
Harmonic Distortion/歪率
(1 kHz)
Mono/Stereo ................................................................. 0.2 / 0.3 %
Stereo Separation/ステレオセパレーション
1 kHz .................................................................................... 42 dB
Frequency Response/周波数特性
20 Hz to 15 kHz .......................................................... +0.5 / -2 dB
Antenna Input/アンテナ入力
...................................................................... 75 ohms unbalanced
■ AM Section/AM部
Tuning Range/受信周波数範囲
U, C models ....................................................... 530 to 1,710 kHz
A, B, G, L, K, J models ...................................... 531 to 1,611 kHz
R, T models ................................ 530 to 1,710 / 531 to 1,611 kHz
Usable Sensitivity/実用感度
........................................................................................ 300 µV/m
Antenna/アンテナ入力
................................................................................. Loop Antenna
■ General/総合
Power Supply/電源電圧
U, C models ........................................................ AC 120 V, 60 Hz
A model ............................................................... AC 240 V, 50 Hz
B, G, L models ....................................................AC 230 V, 50 Hz
R model .................................... AC 110/120/220/240 V, 50/60 Hz
T model ............................................................... AC 220 V, 50 Hz
K model ............................................................... AC 220 V, 60 Hz
J model ........................................................... AC 100V, 50/60 Hz
Power Consumption/消費電力
U, C models ......................................................... 270 W / 360 VA
A, B, G, L, R, T, K models .................................................. 270 W
J model ................................................................................ 220 W
Standby Power Consumption (reference data)/待機電力(参考値)
U, C models ......................................................................... 0.7 W
A, B, G, L models ................................................................. 0.8 W
J model ................................................................................. 0.9 W
Maximum Power Consumption [R model]
(5ch Drive, 10% THD)
RX-V540 (R model) ............................................................. 550 W
RX-V440 (R model) ............................................................. 500 W
AC Outlets/ACアウトレット
2 switched outlets
U, C, G, L, J models ........................................ 100 W max. total
R, T models ........................................................ 50 W max. total
1 switched outlet
A, B models ............................................................... 100W max.
Dimensions/寸法 (W x H x D)
........................ 435 x 161 x 390 mm (17-1/8" x 6-5/16" x 15-3/8")
Weight/重量
.................................................................... 11.0 kg (24 lbs. 4 oz.)
Finish/仕上げ
RX-V540 ................................ Gold color (L, R, T, K) models
Black color (U, C, A, R) models
RX-V440 ................................ Gold color (L, R, T, K) models
Black color (U, C, A, R) models
Silver color (L, R) models
RX-V540RDS/RX-V440RDS ... Gold color (G) model
Black color (B, G) models
Titanium color (B, G) models
HTR-5650 .............................. Gold color (T, K) models
Black color (U, C) models
Silver color (U, C, A) models
HTR-5640 .............................. Gold color (T, K) models
Black color (U, C) models
Silver color (U, C, A) models
HTR-5650RDS/HTR-5640RDS .. Black color (G) model
Silver color (B, G) models
DSP-AX540 ........................... Gold color (J) model
DSP-AX440 ........................... Gold color (J) model
Silver color (J) model
Accessories/付属品
Remote Control, Batteries (Manganese Dry), Indoor FM Antenna,
AM Loop Antenna, PAL 75/300 Socket [B model]
* Specifications are subject to change without notice due to product
improvements.
※ 参考仕様および外観は予告なく変更されることがあります。
U .......... U.S.A. model C ...... Canadian model
A .......... Australian model B ...... British model
G .......... European model L ....... Singapore model
R .......... General model T ....... Chinese model
K .......... Korean model J ....... Japanese model
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are trademarks of
Dolby Laboratories.
ドルビーラボラトリーズからの実施権に基づき製造されていま
す。ドルビー、DOLBY、ドルビーデジタル、PROLOGICおよび
ダブルD記号 は、ドルビーラボラトリーズの商標です。
“DTS”, “DTS-ES Extended Surround” and “Neo: 6” are
trademarks of Digital Theater Systems, Inc.
DTS、DTS-ESExtendedサラウンドおよびNeo:6はデジタルシア
ターシステムズの登録商標です。
AACロゴマーク はドルビーラボラトリーズの商標です。
