RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540
RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440
21
RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540
RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440
■ SELF DIAGNOSIS FUNCTION (DIAG)／自己診断機能（ダイアグ）
No DIAG menu sub-menu
1 DSP THROUGH 1. ANALOG BYPASS
2. YSS 0dB
3. YSS Front 0dB
4. YSS FULL BIT
5. YSS FULL BIT F
2 RAM THROUGH RAM 0dB
3 PRO LOGIC / 1. PRO LOGIC I
NEO6 2. PRO LOGIC II
3. Neo:6
4 SPEAKERS SET 1. MAIN: SMALL 0dB
2. CENTER: NONE
3. LFE/BASS: MAIN
4. Front Mix: 5ch
5. Rear Center power
6. Tone Control Flat
7. Tone Control +10dB
8. Tone Control -10dB
5 MARGIN CHECK 1. MAIN 12 dB margin
2. MAIN 15 dB margin
6 OTHER INPUT EXTERNAL DECODER
7 DISPLAY CHECK 1. VFD CHECK (Initial display)
2. VFD DISP OFF (All segments OFF)
3. VFD DISP ALL (All segments ON 100%)
4. VFD DIMMER (All segments ON 50%)
5. CHECKED PATTERN (ON in lattice)
8 MANUAL TEST 1. TEST ALL
2. TEST MAIN L
3. TEST CENTER
4. TEST MAIN R
5. TEST REAR R
6. TEST REAR CENTER
7. TEST REAR L
8. TEST LFE
9 FACTORY PRESET 1.
PRESET INHIBITED (memory initialization inhibited)
2. PRESET RESERVED (memory initialized)
10 AD DATA CHECK 1. DC/PS (protection)
/FAN TEST 2.
THM/Fan (Not applied to these models / )
3.
REC-OUT (Not applied to these models / )
4. IMP SW/POWER LIMIT
5. K0/K1 (panel key)
6.
FAN DRIVE TEST: HIGH (Not applied to these models / )
7.
FAN DRIVE TEST: MID (Not applied to these models / )
8.
FAN DRIVE TEST: LOW (Not applied to these models / )
There are 15 DIAG menu items, each of which has sub-
menu items.
Listed in the table below are menu items and sub-menu
items.
Note that not all menu items listed will apply to the models
covered in this service manual.
To Next Page
