Yamaha DSP-AX540 - Specifications; 参考仕様

RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540
RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440
RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540
RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440
14
■ SPECIFICATIONS / 参考仕様
■ Audio Section/オーディオ部
Minimum RMS Output Power (Power Amp. Section)/定格出力(パ
ワーアンプ部)
[RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540]
(20 Hz to 20 kHz)
MAIN L/R
U, C models (0.06% THD, 8 ohms) ............. (FTC) 80W + 80W
A, B, G, L, R, T, K models (0.06% THD, 8 ohms) ... 70W + 70W
J model (0.09% THD, 6 ohms) ............................... 80W + 80W
CENTER, REAR CENTER
U, C models (0.06% THD, 8 ohms) ............. (FTC) 80W + 80W
A, B, G, L, R, T, K models (0.06% THD, 8 ohms) ... 70W + 70W
J model (0.09% THD, 6 ohms) ............................... 80W + 80W
REAR L/R
U, C models (0.06% THD, 8 ohms) ............. (FTC) 80W + 80W
A, B, G, L, R, T, K models (0.06% THD, 8 ohms) ... 70W + 70W
J model (0.09% THD, 6 ohms) ............................... 80W + 80W
(1 kHz)
MAIN L/R
U, C models (0.7% THD, 8 ohms) ............... (FTC) 95W + 95W
R, T, K models (0.7% THD, 8 ohms) ...................... 85W + 85W
CENTER, REAR CENTER
U, C models (0.7% THD, 8 ohms) ............... (FTC) 95W + 95W
R, T, K models (0.7% THD, 8 ohms) ...................... 85W + 85W
REAR L/R
U, C models (0.7% THD, 8 ohms) ............... (FTC) 95W + 95W
R, T, K models (0.7% THD, 8 ohms) ...................... 85W + 85W
[RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440]
(20 Hz to 20 kHz)
MAIN L/R
U, C models (0.06% THD, 8 ohms) ............. (FTC) 75W + 75W
A, B, G, L, R, T, K models (0.06% THD, 8 ohms) ... 65W + 65W
J model (0.09% THD, 6 ohms) ............................... 75W + 75W
CENTER, REAR CENTER
U, C models (0.06% THD, 8 ohms) ............. (FTC) 75W + 75W
A, B, G, L, R, T, K models (0.06% THD, 8 ohms) ... 65W + 65W
J model (0.09% THD, 6 ohms) ............................... 75W + 75W
REAR L/R
U, C models (0.06% THD, 8 ohms) ............. (FTC) 75W + 75W
A, B, G, L, R, T, K models (0.06% THD, 8 ohms) ... 65W + 65W
J model (0.09% THD, 6 ohms) ............................... 75W + 75W
(1 kHz)
MAIN L/R
U, C models (0.7% THD, 8 ohms) ............... (FTC) 90W + 90W
T, K, A, B, G models (0.7% THD, 8 ohms) ............ 80W + 80W
CENTER, REAR CENTER
U, C models (0.7% THD, 8 ohms) ............... (FTC) 90W + 90W
T, K, A, B, G models (0.7% THD, 8 ohms) ............ 80W + 80W
REAR L/R
U, C models (0.7% THD, 8 ohms) ............... (FTC) 90W + 90W
T, K, A, B, G models (0.7% THD, 8 ohms) ............ 80W + 80W
Maximum Power/実用最大出力 (EIAJ, 1kHz, 10% THD)
[RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540]
MAIN L/R
R, T, K models (8 ohms) ..................................... 100W + 100W
J model (6 ohms) ................................................ 110W + 110W
CENTER, REAR CENTER
R, T, K models (8 ohms) ..................................... 100W + 100W
J model (6 ohms) ................................................ 110W + 110W
REAR L/R
R, T, K models (8 ohms) ..................................... 100W + 100W
J model (6 ohms) ................................................ 110W + 110W
[RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440]
MAIN L/R
R, T, K models (8 ohms) ......................................... 95W + 95W
J model (6 ohms) ................................................ 100W + 100W
CENTER, REAR CENTER
R, T, K models (8 ohms) ......................................... 95W + 95W
J model (6 ohms) ................................................ 100W + 100W
REAR L/R
R, T, K models (8 ohms) ......................................... 95W + 95W
J model (6 ohms) ................................................ 100W + 100W
DIN Standard Output Power Per Channel/DINパワー [B, G, L
models]
[RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540]
(1 kHz, 0.7% THD, 4 ohms)
MAIN L/R ................................................................. 115W + 115W
CENTER, REAR CENTER ..................................... 115W + 115W
REAR L/R ................................................................ 115W + 115W
[RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440]
(1 kHz, 0.7% THD, 4 ohms)
MAIN L/R ................................................................. 110W + 110W
CENTER, REAR CENTER ..................................... 110W + 110W
REAR L/R ................................................................ 110W + 110W
IEC Power /IECパワー[B, G, L models]
[RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540]
1 kHz, 0.06% THD, 8 ohms ........................................ 80W + 80W
[RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440]
1 kHz, 0.06% THD, 8 ohms ........................................ 75W + 75W
Dynamic Power Per Channel/ダイナミックパワー (IHF)
[RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540]
U, C models (8/6/4/2 ohms) ............................ 100/125/160/200W
A, B, G, L, R, T, K models (8/6/4/2 ohms) ....... 90/110/145/180W
J model (6/4/2 ohms) ............................................. 110/145/180W
[RX-V440/RX-V440RDS/HTR-5640/HTR-5640RDS/DSP-AX440]
U, C models (8/6/4/2 ohms) .............................. 95/120/150/190W
A, B, G, L, R, T, K models (8/6/4/2 ohms) ....... 85/105/140/170W
J model (6/4/2 ohms) ............................................. 105/140/170W
Dynamic Headroom/ダイナミックヘッドルーム
U, C models (8 ohms) .......................................................... 1.0dB
Damping Factor/ダンピングファクタ
20 Hz to 20 kHz, SPEAKER-A, 8 ohms .................... 100 or more
Input Sensitivity / Input Impedance(入力感度/入力インピーダンス)
CD, etc. ......................................................... 150 mV / 47 k-ohms
EXT. DECODER
MAIN L/R, CENTER, SURROUND L/R, SUB WOOFER
.................................................................. 150 mV / 47 k-ohms
Maximum Input Signal Level/最大許容入力
(1 kHz, 0.5% THD, Effect On)
CD, etc. .................................................................................. 2.0V
Output Level / Output Impedance(出力電圧/出力インピーダンス)
REC OUT ..................................................... 150 mV / 1.2 k-ohms
SUB WOOFER (MAIN SP: Small) ...................... 4 V / 1.2 k-ohms
Headphone Jack Rated Output / Impedance(ヘッドフォン出力/出
力インピーダンス)
CD, etc. (1 kHz, 35 mV, 8 ohms) ................... 150 mV / 100 ohms
Frequency Response/周波数特性
CD, etc. to MAIN L/R (10 Hz to 100 kHz) ..................... +0/-3.0dB
Total Harmonic Distortion/全高調波歪率
(20Hz to 20kHz, 40W, 8 ohms)
CD, etc. (Effect Off) to MAIN L/R SP OUT .............. 0.06% or less
Signal to Noise Ratio/信号対雑音比 (IHF-A network)
CD, etc. (Input shorted, EFFECT OFF) to MAIN L/R
250mV .................................................................. 100dB or more
Residual Noise/残留ノイズ (IHF-A network)
MAIN L/R SP OUT .................................................. 150µV or less
Channel Separation/チャンネルセパレーション
(Vol -30 dB, Effect Off)
CD, etc. (Input 5.1 k-ohms shorted, 1 kHz/10 kHz) ... 60 dB or more/45 dB or more
Tone Control Characteristics/トーンコントロール特性
BASS
Boost/Cut ............................................................ ±10dB (60Hz)
TREBLE
Boost/Cut .......................................................... ±10dB (20kHz)
Filter Characteristics/フィルター特性
MAIN, REAR L/R SP Small (H.P.F.) .................. 90Hz / 12dB oct.
SUBWOOFER (L.P.F.) ....................................... 90Hz / 18dB oct.
■ Video Section/ビデオ部
Video Signal Type/ビデオ信号方式
U, C, J models ..................................................................... NTSC
A, B, G, L models .................................................................... PAL
R, T, K models ......................................................... NTSC or PAL
Video Signal Level/ビデオ信号
............................................................................ 1 Vp-p / 75 ohms
S-Video Signal Level/Sビデオ信号
[RX-V540/RX-V540RDS/HTR-5650/HTR-5650RDS/DSP-AX540]
Y ......................................................................... 1 Vp-p / 75 ohms
C .................................................................. 0.286 Vp-p / 75 ohms
Component Signal Level/コンポーネントビデオ信号
Y ......................................................................... 1 Vp-p / 75 ohms
Cb/Cr ............................................................... 0.7 Vp-p / 75 ohms
Maximum Input Level/最大許容入力
.......................................................................................... 1.5 Vp-p
Signal to Noise Ratio/信号対雑音比
................................................................................. 50 dB or more
