28
RX-V757/DSP-AX757/DSP-AX757SE
RX-V657/HTR-5860
RX-V757/DSP-AX757/DSP-AX757SE
RX-V657/HTR-5860
■
SELF DIAGNOSIS FUNCTION (DIAG)/自己診断機能（ダイアグ）
本機には、検査、測定、不良個所の発見を目的にした自己診
断機能（ダイアグ）があります。
ダイアグメニューは20種類あり、そのそれぞれにサブメ
ニューがあります。
This product has a built-in self diagnosis function (DIAG) to
facilitate inspection, measurement and determination of a
faulty item, if any. There are 20 DIAG menu items, each hav-
ing sub-menu items.
No. DIAG menu Sub-menu
1 BYPASS 1.ANALOG BYPASS
2. DSP BYPASS
2 RAM THROUGH 1. RAM MARGIN
2. RAM FULL BIT
3 PRO LOGIC 1. PRO LOGIC
4 SPEAKERS SET 1. FRNT : SML 0dB
2. CENTER : NONE
3. LFE/B : FRNT
4. Pres Mix : 5ch
5. Front GAIN 1
6. Front GAIN 2
7. Zone 2 Amp ON
5 XCH INPUT 1. XCH INPUT_6
2. XCH INPUT_8
6 MIC CHECK 1. MIC CHK
7 VFD CHECK 1. VFD CHECK (Initial display /初期表示)
2. VFD OFF/OSD OFF
3. VFD ALL/OSD 128 character pattern
4. VFD DIMMER/OSD OFF
5. VFD PATTERN/OSD OFF
8 MANUAL TEST 1. TEST ALL
2. TEST FRNT L
3. TEST CENTER
4. TEST FRNT R
5. TEST SURR R
6. TEST SB R
7. TEST SB L
8. TEST SURR L
9. TEST PRES L
10. TEST PRES R
11. TEST LFE
9 FACTORY PRESET 1. PRESET INHI (memory initialization inhibited /メモリーの初期化禁止)
2. PRESET RSRV (memory initialized /メモリーの初期化)
10 AD DATA CHECK 1. DC/PS (protection)
2. THM
3. IMP SW/POWER LIMIT
4. PANEL KEY
11 V CONV STATUS 1. LOW BYTE
2. HIGH BYTE
12 XM STATUS 1. XMS1 (No applied to these models /このモデルには適用されません)
2. XMS2 (No applied to these models /このモデルには適用されません)
13 IF STATUS 1. DST :
2. DMD :
3. DIF :
4. PC :
5. CS1 :
6. CS2 :
7. DEI :
