EMU03100
PROCEDURE
8D, 9.9F, 15F
1) Place the gear shift lever in the neutral
position.
2) Place the tilt lock lever in the release
position.
3) Slightly tilt up the engine. The tilt-sup-
port bar will lock automatically, support-
ing the engine in a partially raised posi-
tion.
NOTE:
This motor has 2 positions for shallow water
cruising.
RETURNING TO ORIGINAL
POSITION
1) Place the tilt lock lever in the lock posi-
tion.
2) Slightly tilt up the engine until the tilt-
support bar automatically returns to the
free position.
3) Then, slowly lower the engine to the
normal position.
