E
4-3
Model Unit 15FMH
Item
DIMENSIONS
Overall length mm (in.)
Overall width mm (in.)
Overall height S/L mm (in.)
Transom height S/L mm (in.)
Weight S/L kg (lb.)
PERFORMANCE
Full throttle operating range r/min
Maximum output kW (HP) @ r/min
Idling speed (in neutral) r/min
ENGINE
Type
Displacement cm
3
(cu.in.)
Bore × stroke mm (in.)
Ignition system
Spark plug NGK
Spark plug gap mm (in.)
Control system
Starting system
Alternator output V-A (W)
Starting carburetion system
DRIVE UNIT
Gear positions
Gear ratio
Trim and tilt system
Propeller mark
FUEL AND OIL
Recommended fuel
Fuel tank capacity L (US gal, Imp gal)
Recommended engine oil
Lubrication
Fuel to oil ratio Fuel:Oil
Recommended gear oil
Gear oil capacity cm
3
(US oz, Imp oz)
TIGHTENING TORQUE
Spark plug N·m (kg·m, lb·ft)
Propeller nut N·m (kgf·m, lb·ft)
873 (34.4)
332 (13.1)
1,040 (40.9) / 1,167 (45.9)
440 (17.3) / 567 (22.3)
36 (79) / 37.5 (83)
4,500–5,500
11 (15) @ 5,000
700–800
2-stroke, L2
246 (15.01)
56 × 50 (2.20 × 1.97)
CDI system
B7HS-10
0.9–1.0 (0.035–0.039)
Tiller control
Manual start
12-(40/80)
Choke start
Forward-Neutral-Reverse
2.08 (27/13)
Manual tilt
J
Regular unleaded gasoline
24 (6.34, 5.28)
YAMALUBE 2 STROKE OUTBOARD OIL
or an equivalent TCW3 certified outboard oil
Premix
50:1
Hypoid gear oil (SAE90)
250 (8.5 , 8.8)
25 (2.55, 18.44)
17 (1.73, 12.54)
EMU18640¯
