– 9 –
AE00111
Oil warning light (red)
When the oil level falls below the lower level, the oil
warning light comes on and then the engine stops
automatically. Unless you refill with oil, the engine will
not start again.
NOTE:
If the engine stalls or does not start, turn the engine
switch to “ON” position and then pull the recoil starter.
If the oil warning light flickers for a few seconds, the
engine oil is insufficient. Add oil and restart.
AE00101
CONTROL FUNCTION
AE00121
Engine switch
The engine switch controls the ignition system.
1 7 “ON”
Ignition circuit is switched on.
The engine can be started.
2 5 “STOP”
Ignition circuit is switched off.
The engine will not run.
3 6 “START”
Starting circuit is switched on.
The starter motor starts and the engine can be started.
After starting the engine, take your hand off the switch
immediately.
å EF5200DE
∫ YG5200D
A
B
7CB-F8199-11_a 07.12.22 16:30 Page 9
